System And Components
1W5082 CYLINDER BLOCK GPENGINE S/N 48W35650-39841
Group No: 1W5082
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W4990 | 1 TUBE AS-OIL JET | 8 | |
| 4N1650 | 2 DOWEL | 4 | |
| 8T6763 | 3 PLUG | 4 | |
| 1103779 | 4 CYLINDER BLOCK AS | 1 | |
| 8T6757 | 5 PLUG-PIPE | 7 | |
| 6N9133 | 6 GASKET-PLATE | 2 | |
| 6I4613 | 7 PLATE-SPACER | 2 | |
| 4N0693 | 8 PLUG-TAPERLOCK 38.10MM(1.50IN)OD | 3 | |
| 7C9614 | PLUG-TAPERLOCK 41.28MM(1.62IN)OD | 3 | |
| 4N0683 | 9 DOWEL | 4 | |
| 7E6479 | 10 BOLT-OIL JET | 8 | |
| 3B0645 | 11 PLUG-CUP | 1 | |
| 6L4428 | 12 STUD-TAPERLOCK | 3 | |
| 1144427 | 13 SEAL-O-RING | 2 | |
| 7W6534 | 14 PLUG-PIPE | 2 | |
| 5P8356 | 15 SEAL-O-RING | 2 | |
| 3S6605 | 16 PLUG-CUP | 2 | |
| 9S4190 | 17 PLUG-O-RING | 2 | |
| 8T6764 | 18 PLUG-PIPE | 1 | |
| 7C7407 | 19 STUD | 1 | |
| 7W6534 | 20 PLUG-PIPE | 1 | |
| 9S4190 | 21 PLUG-O-RING | 2 | |
| 1144427 | SEAL-O-RING | 2 | |
| 7W6534 | 22 PLUG-PIPE | 1 | |
| 7W6534 | 23 PLUG-PIPE | 1 | |
| 7W6534 | 24 PLUG-PIPE | 1 | |
| 4W6061 | SLEEVE-BOTTOM LINER | ||
| 4W4588 | SLEEVE-LIFTER BORE | ||
| 9Y3368 | INSERT-LINER SEAT | ||
| 2W3815 | INSERT-LINER SEAT (1.605-MM THK) | ||
| 5N0093 | INSERT-LINER SEAT | ||
| 1010523 | INSERT-LINER SEAT |
