System And Components
263-5706 MOUNTING GP-MONITOR -CAMERAS/N DNW537-UP
Group No: 263-5706
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2124338 | 1 BRACKET AS | 1 | |
| 7T1099 | LINK | 1 | |
| 2331854 | 2 MOUNT | 1 | |
| 2331855 | 3 HOLDER AS | 1 | |
| 2105732 | ENCAPSULANT | 1 | |
| 2465837 | 6 HARNESS AS-MONITOR | 1 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 2 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 8 | |
| 1305300 | 8 CLIP | 1 | |
| 6V8225 | 9 NUT (M6X1-THD) | 4 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4133 | 11 NUT (M10X1.5-THD) | 2 | |
| 8T4191 | 12 BOLT (M10X1.5X16-MM) | 2 | |
| 8T4195 | 13 BOLT (M10X1.5X30-MM) | 2 | |
| 9X2038 | 14 WASHER (7X19X2-MM THK) | 4 | |
| 9X2044 | 15 SCREW-TRUSS HEAD (M6X1X16-MM) | 2 | |
| 9X2045 | 16 SCREW-TRUSS HEAD (M6X1X20-MM) | 2 | |
| 9X8267 | 17 WASHER (6.6X12X2-MM THK) | 4 | |
| 2232666 | 18 MONITOR & MOUNTING GP | 1 |
