System And Components
304-6330 BATTERY & WIRING GP -4-POST DISCONNECTS/N CXM383-UP
Group No: 304-6330
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2551012 | 1 CABLE AS | 1 | |
| 2864612 | CABLE (56-CM) | ||
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 3S6049 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 8N1725 | COVER AS-TERMINAL (RED) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 9X4519 | BOOT (RED) | 1 | |
| 2551010 | 2 CABLE AS | 1 | |
| 2864612 | CABLE (109-CM) | ||
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 2 | |
| 9X4519 | BOOT (RED) | 2 | |
| 2551011 | 3 CABLE AS | 1 | |
| 2864612 | CABLE (191-CM) | ||
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 2551013 | 4 CABLE AS | 1 | |
| 2864612 | CABLE (154-CM) | ||
| 6T0465 | COVER-TERMINAL (BLACK) | 1 | |
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 3S6050 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 3462487 | 5 HARNESS AS-POWER (STARTER) | 1 | |
| 1082515 | COVER-TERMINAL | 1 | |
| 2550224 | 6 CABLE AS | 1 | |
| 2864612 | CABLE (46-CM) | ||
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 9G0549 | 7 CABLE AS | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 2 | |
| 1598050 | CABLE (00-GA, BLACK)(20-CM) | ||
| 9G0003 | COVER AS-TERMINAL (BLACK) | 1 | |
| 9G0004 | COVER AS-TERMINAL (RED) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 2 | |
| 8C5917 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 8T9757 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 2551014 | 8 HARNESS AS-SWITCH | 1 | |
| 9X4519 | BOOT (RED) | 1 | |
| 8S2633 | RECEPTACLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 6T0465 | 9 COVER-TERMINAL (BLACK) | 2 | |
| 4K8302 | 10 CLIP (LOOP) | 1 | |
| 8T4137 | 11 BOLT (M10X1.5X20-MM) | 8 | |
| 0338248 | 12 CLIP (LOOP) | 7 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 15 | |
| 8T6466 | 14 BOLT (M10X1.5X60-MM) | 2 | |
| 2G8767 | 15 WASHER (10.5X60X3-MM THK) | 6 | |
| 2536273 | 16 INSULATOR | 4 | |
| 7Y3195 | 17 GROMMET | 1 | |
| 2169890 | 18 FUSE GP (CORROSION RESISTANT) | 1 | |
| 9X6155 | 19 BOLT-SOCKET HEAD (M6X1X16.7-MM) | 2 | |
| 2104757 | 20 NUT (1/2-13-THD) | 2 | |
| 9X9730 | 21 BATTERY GP (12-VOLT)(DRY) | 2 | |
| 7N0060 | VENT AS | 6 | |
| 3076402 | 22 SWITCH-DISCONNECT (4-POLE)(BATTERY) | 1 | |
| 1712210 | 23 CIRCUIT BREAKER AS (80-AMPERE) | 1 | |
| 1H3244 | LOCKWASHER | 2 | |
| 8T0122 | NUT-FULL (1/4-28-THD) | 2 | |
| 4E5724 | WASHER (7X12X1-MM THK) | 2 | |
| 2S9556 | 24 SCREW-MACHINE (10-32X0.875-IN) | 2 | |
| 2104756 | 25 WASHER (13X25X2MM THK) | 2 | |
| 4W7627 | 26 SPACER (11X19X37-MM THK) | 4 | |
| 2692302 | 27 CLAMP | 1 | |
| 6C7474 | 28 ROD | 1 | |
| 8T4223 | 29 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V7687 | 30 LOCKNUT (M12X1.75-THD) | 2 | |
| 4M1111 | 31 MAT | 2 | |
| 8T4196 | 32 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4133 | 33 NUT (M10X1.5-THD) | 4 | |
| 8T4200 | 34 BOLT (M8X1.25X16-MM) | 4 | |
| 2692303 | 35 COVER | 1 | |
| 1264133 | 36 COVER AS | 1 | |
| 8T4224 | 37 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T6685 | 38 BOLT (M10X1.5X110-MM) | 1 | |
| 3076391 | 39 ISOLATOR | 1 | |
| 5P8187 | 40 CONNECTOR | 1 | |
| 1160118 | 41 CLIP | 1 | |
| 8T4896 | 42 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 3180734 | 43 HARNESS AS-SWITCH (BATTERY ISOLATION) | 1 | |
| 4D7794 | 44 CLIP | 1 | |
| 1305300 | 45 CLIP | 1 | |
| 3071120 | 46 FILM-IDENTIFICATION (BATTERY DISCONNECT) | 1 | |
| 3114438 | 47 HARNESS AS-SWITCH (4-POLE) | 1 | |
| 0815930 | 48 CABLE AS-CHASSIS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 2 |
