System And Components
267-6729 WIRING GP-REARS/N CXM1-UP
Group No: 267-6729
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2106305 | 1 BRACKET | 1 | |
| 8T4137 | 2 BOLT (M10X1.5X20-MM) | 18 | |
| 8T4121 | 3 WASHER-HARD (11X21X2.5-MM THK) | 24 | |
| 6D4246 | 4 CLIP (LOOP) | 16 | |
| 2676728 | 5 HARNESS AS-HITCH | 1 | |
| 0815930 | 6 CABLE AS-CHASSIS | 2 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 2 | |
| 8T4133 | 7 NUT (M10X1.5-THD) | 2 | |
| 8R3600 | 8 ANGLE | 2 | |
| 4B5324 | 9 WASHER (3.9X9.6X1.2-MM THK) | 4 | |
| 9X6258 | 10 SCREW-MACHINE (6-32X0.5-IN) | 4 | |
| 8T4136 | 11 BOLT (M10X1.5X25-MM) | 3 | |
| 4W7627 | 12 SPACER (11X19X37-MM THK) | 1 | |
| 8T6466 | 13 BOLT (M10X1.5X60-MM) | 1 |
