178-9085 FINAL DRIVE & BRAKE GPS/N CXM1-UP

Group No: 178-9085

Part Number	Part Name	Qty
2D6511	1 CUP-BEARING	1
2P8353	2 CONE-BEARING	1
1783004	3 CONE-BEARING	1
1783005	4 CUP-BEARING	1
1S3889	5 WASHER	1
2D9572	6 SEAL-O-RING	1
4D3151	7 BEARING AS-ROLLER	6
4H6730	8 SEAL-O-RING	1
5H4909	9 SEAL-O-RING	1
6V4244	10 SEAL-O-RING	1
8E9571	11 WASHER-HARD (8.8X16X7-MM THK)	3
8K0066	12 SHIM (0.112-IN THK)	1
8M3837	13 PLUG-MAGNETIC (FINAL DRIVE, OIL CHECK)	1
9W5977	14 SEAL GP-DUO-CONE	1
5P1606	RING-TORIC	2
1100550	15 RING-RETAINING	1
1100552	16 HUB AS	1
8K0079	16A BUSHING-TERMINAL	1
1102056	17 COVER AS	1
1U8846	SEALANT-GASKET
0994691	BOLT-LOCKING (M12X1.75X25-MM)	2
1097848	BUTTON	1
1634526	18 WASHER-THRUST (72.5X94X5-MM THK)	1
1634527	19 PLATE-BEARING	1
1800014	20 CARRIER-PLANETARY	1
1800015	21 SPACER (62X85.9X10.5-MM THK)	3
1800016	22 WHEEL (62-TEETH)	1
1800018	23 RETAINER	2
1800020	24 BRAKE GP-SERVICE & PARKING	1
1800026	25 SPACER (62X85.9X10.5-MM THK)	1
1959706	26 SEAL GP-DUO-CONE	1
2035527	27 WASHER-THRUST (61X106X1.5-MM THK)	6
2035528	28 WASHER-THRUST (61X106X1.5-MM THK)	6
2169718	29 GEAR-RING (79-TEETH)	1
2497870	30 GEAR-SUN (17-TEETH)	1
2611082	31 GEAR-PLANETARY (29-TEETH)	3
3697660	32 SHAFT	3
3927976	33 SPINDLE	1
1J9671	34 SEAL-O-RING	2
2S0736	35 WASHER-HARD (17X27X3.5-MM THK)	10
5F1678	38 SEAL-O-RING	1
6T5545	39 DOWEL	3
6V5844	40 BOLT (M16X2X35-MM)	6
7M8485	41 SEAL-O-RING	1
8T2393	42 BOLT-SOCKET HEAD (M16X2X60-MM)	10
8T5091	43 BOLT (M8X1.25X20-MM)	3
8T8441	44 BOLT-SOCKET HEAD (M12X1.75X25-MM)	3
9S4205	45 PLUG (1-5/16-12-THD)	1
9S8003	46 PLUG (1/2-20-THD)	2
9X8268	49 WASHER (17.5X30X3.5-MM THK)	6
