System And Components
240-8763 LINES GP-FIRE SUPPRESSION -AUTOMATIC DETONATIONS/N CXM1-UP
Group No: 240-8763
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2114489 | 1 ACTUATOR AS | 2 | |
| 2031182 | 1A TAG-WARNING (FIRE SUPPRESSION) | 1 | |
| 3137183 | 1B FILM-INSTRUCTION (FIRE EXTINGUISHER, FOAM) | 1 | |
| 3P5414 | 2 GROMMET | 1 | |
| 2114510 | 3 HOSE (5-M) | ||
| 2114510 | 3A HOSE (1-M) | ||
| 2114491 | 4 HOSE AS | 1 | |
| 0055421 | 5 TEE-UNION | 3 | |
| 2114495 | 6 HOSE AS | 1 | |
| 2114496 | 7 VALVE AS | 1 | |
| 1664206 | VALVE (CHARGE) | 1 | |
| 1868161 | CAP | 1 | |
| 2114497 | 8 HOSE AS | 1 | |
| 2179919 | 9 HOSE AS | 1 | |
| 8T4137 | 10 BOLT (M10X1.5X20-MM) | 24 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 45 | |
| 0338248 | 12 CLIP (LOOP) | 40 | |
| 2114499 | 13 TEE | 1 | |
| 3E7808 | 14 SWITCH AS-PRESSURE (HYDRAULIC) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 2179915 | 15 HOSE AS | 1 | |
| 8T4133 | 16 NUT (M10X1.5-THD) | 1 | |
| 2427287 | 17 HOSE AS | 1 | |
| 3J1907 | 18 SEAL-O-RING | 1 | |
| 2408759 | 19 HOSE AS | 1 | |
| 2114507 | 20 SLEEVE | 15 | |
| 5C2874 | 21 NUT (M5X0.8-THD) | 4 | |
| 8T0328 | 22 WASHER-HARD (5.5X10X1-MM THK) | 4 | |
| 8T4224 | 23 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4200 | 24 BOLT (M8X1.25X16-MM) | 2 | |
| 2114513 | 25 CAP-END | 2 | |
| 2030435 | 26 COUPLING AS (HOSE) | 4 | |
| 2114514 | 27 SLEEVE | 4 | |
| 2030436 | 28 ADAPTER | 2 | |
| 2114541 | 30 BRACKET | 1 | |
| 2114542 | 31 TUBE-SIPHON | 1 | |
| 1S9593 | 32 STRAP-CABLE | 3 | |
| 8T6466 | 33 BOLT (M10X1.5X60-MM) | 2 | |
| 2114532 | 34 COVER | 1 | |
| 2031495 | 35 STRAP | 1 | |
| 2114533 | 36 CYLINDER GP-RETARDANT | 1 | |
| 2114538 | 37 VALVE GP-RETARDANT CYLINDER | 1 | |
| 2427288 | 44 HOSE AS | 1 | |
| 2408761 | 45 HOSE AS | 1 | |
| 8R3600 | 46 ANGLE | 1 | |
| 4K8864 | 47 CLIP (LOOP) | 3 | |
| 8T4136 | 48 BOLT (M10X1.5X25-MM) | 1 | |
| 4877072 | 49 FOAM | 1 | |
| 3137182 | 50 FILM-IDENTIFICATION (FIRE EXTINGUISHER) | 2 | |
| 3137181 | 51 FILM-IDENTIFICATION | 2 |
