System And Components
251-8504 LINES GP-FIRE SUPPRESSION -RETARDANTS/N CXM1-UP
Group No: 251-8504
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2114506 | 1 HOSE AS | 2 | |
| 2114503 | 2 HOSE AS | 1 | |
| 2886444 | 3 HOSE AS | 1 | |
| 4E5753 | 4 BRACKET | 1 | |
| 2114508 | 5 HOSE AS | 1 | |
| 2114511 | 6 HOSE AS | 1 | |
| 2428056 | 7 HOSE AS | 1 | |
| 2114515 | 8 HOSE AS | 1 | |
| 2518503 | 9 HOSE AS | 1 | |
| 2638622 | 10 HOSE AS | 1 | |
| 2114520 | 11 VALVE-CHECK (FIRE SUPPRESSION) | 1 | |
| 2577505 | 12 HOSE AS | 1 | |
| 2114521 | 13 BRACKET | 2 | |
| 2114522 | 14 CLAMP | 2 | |
| 8T4183 | 15 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4223 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 11 | |
| 8T4137 | 17 BOLT (M10X1.5X20-MM) | 26 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 24 | |
| 6D4246 | 19 CLIP (LOOP) | 29 | |
| 5P1075 | 20 WASHER-HARD (10.2X22.5X3-MM THK) | 9 | |
| 2030394 | 21 TEE | 6 | |
| 2030429 | 22 ADAPTER-NOZZLE | 11 | |
| 1868169 | 23 NOZZLE | 11 | |
| 1868160 | 24 CAP | 11 | |
| 2030432 | 25 FITTING | 3 | |
| 2114524 | 26 WASHER | 6 | |
| 2114525 | 27 BRACKET | 3 | |
| 2030373 | 28 TEE | 2 | |
| 1868148 | 29 FITTING | 3 | |
| 2030401 | 31 BRACKET | 6 | |
| 2030393 | 32 ELBOW | 2 | |
| 8T4136 | 33 BOLT (M10X1.5X25-MM) | 2 | |
| 2114526 | 34 ELBOW | 1 | |
| 2114527 | 35 TEE | 5 | |
| 2142085 | 36 PLUG | 1 | |
| 8T4191 | 37 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4133 | 38 NUT (M10X1.5-THD) | 2 | |
| 2030375 | 42 FITTING | 1 | |
| 6A5591 | 43 BOLT (M12X1.75X25-MM) | 7 | |
| 8T4244 | 44 NUT (M12X1.75-THD) | 4 | |
| 2030374 | 46 TEE | 2 | |
| 2414992 | 47 BRACKET | 2 | |
| 2114529 | 48 FITTING | 2 | |
| 2114528 | 49 PLUG | 1 | |
| 2030376 | BUSHING-REDUCER | 1 |
