System And Components
274-9629 LINES GP-FIRE SUPPRESSION -AUTOMATIC DETONATIONS/N CXM1-354; CXM356-382
Group No: 274-9629
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0338248 | 1 CLIP (LOOP) | 34 | |
| 7K1181 | 2 STRAP-CABLE | 2 | |
| 2114541 | 3 BRACKET | 2 | |
| 1W8795 | 4 BRACKET | 4 | |
| 8T4121 | 5 WASHER-HARD (11X21X2.5-MM THK) | 45 | |
| 8T4133 | 6 NUT (M10X1.5-THD) | 11 | |
| 8T4195 | 7 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4137 | 8 BOLT (M10X1.5X20-MM) | 22 | |
| 4W7627 | 9 SPACER (11X19X37-MM THK) | 1 | |
| 8T6466 | 10 BOLT (M10X1.5X60-MM) | 1 | |
| 1348226 | 11 BRACKET | 2 | |
| 9M4136 | 12 SPACER (0.438X0.75X0.5-IN THK) | 1 | |
| 2030435 | 13 COUPLING AS (HOSE) | 4 | |
| 2255283 | SLEEVE | 1 | |
| 8T4196 | 14 BOLT (M10X1.5X35-MM) | 1 | |
| 2114514 | 15 SLEEVE | 4 | |
| 2030436 | 16 ADAPTER | 4 | |
| 8R3600 | 17 ANGLE | 1 | |
| 2114507 | 18 SLEEVE | 14 | |
| 2114513 | 19 CAP-END | 2 | |
| 2114494 | 20 ADAPTER-TEE | 3 | |
| 2485629 | 21 ADAPTER | 1 | |
| 2114496 | 22 VALVE AS | 1 | |
| 1664206 | VALVE (CHARGE) | 1 | |
| 1868161 | CAP | 1 | |
| 2114489 | 23 ACTUATOR AS | 2 | |
| 2031182 | TAG-WARNING (FIRE SUPPRESSION) | 1 | |
| 3137183 | FILM-INSTRUCTION (FIRE EXTINGUISHER, FOAM) | 1 | |
| 5C2874 | 24 NUT (M5X0.8-THD) | 8 | |
| 8T0328 | 25 WASHER-HARD (5.5X10X1-MM THK) | 8 | |
| 8T4224 | 26 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4199 | 27 BOLT (M8X1.25X12-MM) | 4 | |
| 8T4136 | 28 BOLT (M10X1.5X25-MM) | 6 | |
| 2816168 | 29 HOSE AS | 1 | |
| 2408761 | 30 HOSE AS | 1 | |
| 2427288 | 31 HOSE AS | 1 | |
| 2751869 | 32 HOSE AS | 1 | |
| 2704056 | 33 HOSE AS | 1 | |
| 2256572 | 34 HOSE AS | 1 | |
| 2114538 | 35 VALVE GP-RETARDANT CYLINDER | 1 | |
| 2114533 | 36 CYLINDER GP-RETARDANT | 1 | |
| 2114542 | 37 TUBE-SIPHON | 1 | |
| 2114510 | 38 HOSE (1.3-M) | ||
| 2114510 | 38A HOSE (0.4-M) | ||
| 2114510 | 38B HOSE (2.2-M) | ||
| 2429293 | 39 HOSE AS | 1 | |
| 3P5414 | 40 GROMMET | 1 | |
| 2816169 | 41 HOSE AS | 1 | |
| 3E7808 | 42 SWITCH AS-PRESSURE | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 3J1907 | 43 SEAL-O-RING | 1 | |
| 2114499 | 44 TEE | 1 | |
| 2746384 | 45 HOSE AS | 1 | |
| 7Y7388 | 46 SCREW-BUTTON HEAD (M5X0.8X12-MM) | 8 | |
| 2786928 | 47 FILM-IDENTIFICATION (FIRE SUPPRESSION ACTIVATION) | 2 | |
| 5P1075 | 48 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 1868214 | BLOCK-FOAM | 1 |
