System And Components
274-9647 LINES GP-FIRE SUPPRESSION -RETARDANTS/N CXM1-UP
Group No: 274-9647
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2030429 | 1 ADAPTER-NOZZLE | 11 | |
| 1W8795 | 2 BRACKET | 1 | |
| 7K1181 | 3 STRAP-CABLE | 6 | |
| 8R3600 | 4 ANGLE | 1 | |
| 1868148 | 5 FITTING | 3 | |
| 1868160 | 6 CAP | 11 | |
| 1868169 | 7 NOZZLE | 11 | |
| 2030372 | 8 FITTING | 1 | |
| 2030373 | 9 TEE | 2 | |
| 2030375 | 10 FITTING | 2 | |
| 2030376 | 11 BUSHING-REDUCER | 1 | |
| 2030393 | 12 ELBOW | 3 | |
| 2030394 | 13 TEE | 8 | |
| 2030401 | 14 BRACKET | 2 | |
| 2030432 | 15 FITTING | 3 | |
| 2114512 | 16 HOSE AS | 1 | |
| 2114515 | 17 HOSE AS | 1 | |
| 2114520 | 18 VALVE-CHECK (FIRE SUPPRESSION) | 1 | |
| 2114521 | 19 BRACKET | 2 | |
| 2114522 | 20 CLAMP | 2 | |
| 2114524 | 21 WASHER | 6 | |
| 2114525 | 22 BRACKET | 3 | |
| 2114526 | 23 ELBOW | 1 | |
| 2114527 | 24 TEE | 2 | |
| 2114528 | 25 PLUG | 1 | |
| 2114529 | 26 FITTING | 2 | |
| 2142085 | 27 PLUG | 1 | |
| 2378314 | 28 FITTING | 2 | |
| 2414984 | 29 HOSE AS | 1 | |
| 2414992 | 30 BRACKET | 4 | |
| 2485639 | 31 HOSE AS | 1 | |
| 2518503 | 32 HOSE AS | 1 | |
| 2750705 | 33 HOSE AS | 1 | |
| 2750706 | 34 HOSE AS | 1 | |
| 2750707 | 35 HOSE AS | 1 | |
| 2750708 | 36 HOSE AS | 1 | |
| 2816176 | 37 HOSE AS | 1 | |
| 3187950 | 38 HOSE AS | 1 | |
| 2030374 | 39 TEE | 2 | |
| 2B0941 | 40 SPACER (10.5X19X19-MM THK) | 1 | |
| 3445675 | 41 NUT (M10X1.5-THD) | 7 | |
| 5P1075 | 42 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 6A5591 | 43 BOLT (M12X1.75X25-MM) | 6 | |
| 6D4246 | 44 CLIP (LOOP) | 22 | |
| 7X7729 | 45 WASHER (11X25X3-MM THK) | 2 | |
| 8T4121 | 46 WASHER-HARD (11X21X2.5-MM THK) | 23 | |
| 8T4136 | 47 BOLT (M10X1.5X25-MM) | 5 | |
| 8T4137 | 48 BOLT (M10X1.5X20-MM) | 11 | |
| 8T4186 | 49 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4194 | 50 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4195 | 51 BOLT (M10X1.5X30-MM) | 3 | |
| 8T4223 | 52 WASHER-HARD (13.5X25.5X3-MM THK) | 14 | |
| 8T4244 | 53 NUT (M12X1.75-THD) | 4 |
