System And Components
316-2742 LINES GP-FIRE SUPPRESSION -AUTOMATIC DETONATIONS/N CXM383-UP
Group No: 316-2742
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1K4129 | 1 SPACER (0.423X0.675X0.375-MM THK) | 2 | |
| 1W8795 | 2 BRACKET | 4 | |
| 3E7808 | 3 SWITCH AS-PRESSURE (FIRE SUPPRESSION) | 1 | |
| 7K1181 | 4 STRAP-CABLE | 15 | |
| 8R3600 | 5 ANGLE | 1 | |
| 1348226 | 6 BRACKET | 2 | |
| 2030435 | 7 COUPLING AS (HOSE) | 4 | |
| 2255283 | SLEEVE | 1 | |
| 2030436 | 8 ADAPTER | 2 | |
| 2031182 | 9 TAG-WARNING (FIRE SUPPRESSION) | 2 | |
| 2114489 | 10 ACTUATOR AS | 2 | |
| 2031182 | TAG-WARNING (FIRE SUPPRESSION) | 1 | |
| 3137183 | FILM-INSTRUCTION (FIRE EXTINGUISHER, FOAM) | 1 | |
| 2114496 | 11 VALVE AS | 1 | |
| 1664206 | VALVE (CHARGE) | 1 | |
| 1868161 | CAP | 1 | |
| 2114499 | 12 TEE | 1 | |
| 2114507 | 13 SLEEVE | 15 | |
| 2114513 | 14 CAP-END | 2 | |
| 2114514 | 15 SLEEVE | 4 | |
| 2114533 | 16 CYLINDER GP-RETARDANT | 1 | |
| 2114538 | 17 VALVE GP-RETARDANT CYLINDER | 1 | |
| 2114541 | 18 BRACKET | 2 | |
| 2114542 | 19 TUBE-SIPHON | 1 | |
| 2256572 | 20 HOSE AS | 1 | |
| 2408761 | 21 HOSE AS | 1 | |
| 2427288 | 22 HOSE AS | 1 | |
| 2429293 | 23 HOSE AS | 1 | |
| 2485629 | 24 ADAPTER | 1 | |
| 2704056 | 25 HOSE AS | 1 | |
| 2746384 | 26 HOSE AS | 1 | |
| 2751869 | 27 HOSE AS | 1 | |
| 2816168 | 28 HOSE AS | 1 | |
| 2816169 | 29 HOSE AS | 1 | |
| 3137181 | 30 FILM-IDENTIFICATION | 2 | |
| 3137182 | 31 FILM-IDENTIFICATION (FIRE EXTINGUISHER) | 2 | |
| 3137183 | 32 FILM-INSTRUCTION (FIRE EXTINGUISHER, FOAM) | 2 | |
| 4877072 | 33 FOAM | 1 | |
| 0338248 | 34 CLIP (LOOP) | 33 | |
| 2114494 | 35 ADAPTER-TEE | 3 | |
| 3445675 | 36 NUT (M10X1.5-THD) | 9 | |
| 3J1907 | 37 SEAL-O-RING | 1 | |
| 3P5414 | 38 GROMMET | 2 | |
| 4W7627 | 39 SPACER (11X19X37-MM THK) | 1 | |
| 5C2874 | 40 NUT (M5X0.8-THD) | 8 | |
| 7Y7388 | 41 SCREW-BUTTON HEAD (M5X0.8X12-MM) | 8 | |
| 8T0328 | 42 WASHER-HARD (5.5X10X1-MM THK) | 16 | |
| 8T4121 | 43 WASHER-HARD (11X21X2.5-MM THK) | 41 | |
| 8T4136 | 44 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4137 | 45 BOLT (M10X1.5X20-MM) | 20 | |
| 8T4195 | 46 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 47 BOLT (M10X1.5X35-MM) | 3 | |
| 8T4200 | 48 BOLT (M8X1.25X16-MM) | 4 | |
| 8T4224 | 49 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T6466 | 50 BOLT (M10X1.5X60-MM) | 1 | |
| 9M4136 | 51 SPACER (0.438X0.75X0.5-IN THK) | 1 | |
| 2114510 | 52 HOSE (1.3-M) | ||
| 2114510 | 52A HOSE (0.6-M) | ||
| 2114510 | 52B HOSE (2.2-M) | ||
| 1868214 | BLOCK-FOAM | 1 |
