System And Components
451-1576 LINES GP-BRAKE COOLING -FRONTS/N CXM1-UP
Group No: 451-1576
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 1 | |
| 2096512 | 2 MANIFOLD | 1 | |
| 2096513 | 3 ADAPTER | 2 | |
| 2096514 | 4 ADAPTER | 2 | |
| 2096518 | 5 HOSE AS | 2 | |
| 2096519 | 6 HOSE AS | 1 | |
| 2096520 | 7 HOSE AS | 1 | |
| 1488335 | 8 CONNECTOR AS | 3 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488355 | 9 ELBOW AS | 3 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9005 | ELBOW | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488357 | 10 ELBOW AS | 2 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1503065 | 11 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V0484 | ELBOW | 1 | |
| 1P4579 | 12 FLANGE-HALF | 4 | |
| 2N0412 | 13 BOLT-SOCKET HEAD (7/16-14X2-IN) | 8 | |
| 3J1907 | 14 SEAL-O-RING | 2 | |
| 4J0522 | 15 SEAL-O-RING | 2 | |
| 5F8000 | 16 SEAL-O-RING | 2 | |
| 6V0852 | 17 CAP-DUST | 2 | |
| 6V3965 | 18 FITTING (QUICK DISCONNECT) | 2 | |
| 7G5984 | 19 CLIP (TAB) | 1 | |
| 7G5985 | 20 CLIP (SLOT) | 1 | |
| 7G5986 | 21 GROMMET | 1 | |
| 8T4183 | 22 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4223 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 21 | |
| 8T4956 | 24 BOLT (M12X1.75X35-MM) | 2 | |
| 8T5001 | 25 BOLT (M12X1.75X130-MM) | 3 | |
| 8T8919 | 26 BOLT (1/2-13X1.75-IN) | 8 |
