System And Components
478-1929 LINES GP-BRAKE RELEASES/N CXM567-UP
Group No: 478-1929
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4T0345 | 1 VALVE-CHECK | 2 | |
| 1238915 | 2 PUMP & MOTOR GP (BRAKE RELEASE) | 1 | |
| 2116145 | 3 ADAPTER | 1 | |
| 2136440 | 4 HOSE AS | 1 | |
| 2644692 | 5 HOSE AS | 1 | |
| 4781928 | 6 HOSE AS | 1 | |
| 0314136 | 7 TEE-FLARED | 1 | |
| 2M9780 | 8 SEAL-O-RING | 2 | |
| 3K0360 | 9 SEAL-O-RING | 2 | |
| 4J5267 | 10 SEAL-O-RING | 1 | |
| 5P3166 | 11 TEE-SWIVEL | 1 | |
| 6D4244 | 12 CLIP (LOOP) | 6 | |
| 6J7366 | 13 CAP-FLARED | 1 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4133 | 15 NUT (M10X1.5-THD) | 4 | |
| 8T4137 | 16 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4191 | 17 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4896 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 8T7004 | 19 STUD-TAPERLOCK (M10X1.5X35-MM) | 4 | |
| 8T9377 | 20 BOLT (3/8-16X2.25-IN) | 4 | |
| 9M4584 | 21 CONNECTOR | 1 |
