System And Components
275-8565 VALVE & MTG GP-ACCUM CHARGINGS/N CXM1-422
Group No: 275-8565
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8C2948 | 1 ADAPTER-TEE | 2 | |
| 1869415 | 2 BRACKET | 1 | |
| 2350253 | 3 VALVE GP-ACCUMULATOR CHARGING (BRAKE) | 1 | |
| 6V3965 | 4 FITTING (QUICK DISCONNECT) | 2 | |
| 6V0852 | 5 CAP-DUST | 2 | |
| 8T4191 | 6 BOLT (M10X1.5X16-MM) | 2 | |
| 3J1907 | 7 SEAL-O-RING | 11 | |
| 0307947 | 8 ADAPTER-ELBOW | 1 | |
| 2P7214 | 9 ADAPTER-ELBOW | 1 | |
| 1057704 | 10 TEE | 1 | |
| 6V0484 | 11 ELBOW | 1 | |
| 3E7410 | 12 TEE | 1 | |
| 3274608 | 13 SWITCH AS-PRESSURE (PARKING BRAKE OIL) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 9X1813 | SLEEVE (28-CM) | ||
| 3E7806 | 14 SWITCH AS-PRESSURE (BRAKE ACCUMULATOR CHARGE) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 5 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 4K6297 | 15 ELBOW | 1 | |
| 3K0360 | 16 SEAL-O-RING | 1 | |
| 1393285 | KIT-BRAKE CHARGE VALVE | 1 |
