System And Components
378-7600 AIR CONDITIONER GP -CORROSION RESISTANTS/N CXM567-UP
Group No: 378-7600
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2486772 | 1 SCREW-MACHINE (8-16X7.75-IN) | 8 | |
| 3664138 | 2 VALVE-EXPANSION | 1 | |
| 3787543 | 3 GASKET | 1 | |
| 3787557 | 4 CLIP-CONNECTOR | 1 | |
| 1466371 | 5 LOUVER AS | 4 | |
| 3787565 | 6 BLOWER AS | 1 | |
| 3787566 | 7 PLATE | 1 | |
| 3787567 | 8 VALVE-WATER | 1 | |
| 2883657 | 9 SCREW-THUMB (M6X1X10-MM) | 2 | |
| 3787602 | 10 THERMOSTAT | 1 | |
| 3787603 | 11 HOUSING AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 27 | |
| 1305300 | CLIP | 1 | |
| 3787604 | 12 COVER AS | 1 | |
| 3787605 | 13 PANEL GP-CONTROL | 1 | |
| 3787607 | 14 COIL AS-EVAPORATOR | 1 | |
| 3787608 | 15 HARNESS AS-HEATER & AIR COND | 1 | |
| 3787609 | 16 FILTER (AIR CONDITIONER) | 1 | |
| 3787620 | 17 GRILL | 1 | |
| 3787624 | 18 BRACKET | 1 | |
| 3787625 | 19 PLATE-COVER | 1 | |
| 3787626 | 20 PLATE-COVER | 1 | |
| 3787628 | 21 PLATE AS-BLOWER | 1 | |
| 0688993 | 22 GROMMET | 1 | |
| 1728591 | 23 NUT-CLIP (M6X1-THD) | 1 | |
| 1P8116 | 24 SEAL-O-RING | 2 | |
| 3S2093 | 25 STRAP-CABLE | 4 | |
| 4D2297 | 26 SEAL-O-RING | 1 | |
| 4P8134 | 27 CLIP (LADDER) | 1 | |
| 5L2579 | 28 GROMMET | 4 | |
| 7Y3173 | 29 SCREW-BUTTON HEAD (M4X0.7X12-MM) | 8 | |
| 8F6324 | 30 GROMMET | 1 | |
| 8T4896 | 31 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8T6411 | 32 SCREW-MACHINE (M6X1X12-MM) | 2 | |
| 9X2044 | 33 SCREW-TRUSS HEAD (M6X1X16-MM) | 30 | |
| 9X2480 | 34 BOLT (M6X1X45-MM) | 1 | |
| 9X8256 | 35 WASHER (6.6X12X2-MM THK) | 1 | |
| 5P7070 | 36 INSULATION-STRIP (1-M) |
