System And Components
262-7347 CONTROL GP-TRANSMISSIONS/N CXM1-UP
Group No: 262-7347
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T8908 | 1 BOLT (1/4-20X1-IN) | 3 | |
| 6G4092 | 2 BUSHING | 2 | |
| 6G0001 | 3 SHAFT | 1 | |
| 3242070 | 4 LEVER AS | 1 | |
| 9X2042 | SCREW-TRUSS HEAD (M6X1X12-MM) | 2 | |
| 6V7699 | 5 WASHER-HARD (5.5X13X1.6-MM THK) | 2 | |
| 3L2540 | 6 BOLT-SOCKET HEAD (10-24X0.75-IN) | 2 | |
| 8T5391 | 7 BOLT (5/16-18X0.5-IN) | 2 | |
| 8T4205 | 8 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 8W0976 | 9 HOUSING | 1 | |
| 9S8001 | 10 PLUG (5/16-24-THD) | 4 | |
| 4J7533 | 11 SEAL-O-RING | 4 | |
| 6G4093 | 12 SPRING | 4 | |
| 6G4134 | 13 PIN | 4 | |
| 5B9318 | 14 BALL | 4 | |
| 1253365 | 15 KNOB | 1 | |
| 2514410 | 16 GUIDE | 1 | |
| 2107805 | 17 BRACKET AS | 1 | |
| 5C7261 | NUT (M8X1.25-THD) | 2 | |
| 9R2613 | BOSS-WELD (M10X1.5X25-MM) | 3 | |
| 3031681 | PLATE | 1 | |
| 1267896 | 18 SENSOR GP-POSITION (TRANSMISSION CONTROL) | 1 | |
| 8T8928 | SEAL-LIP TYPE | 1 | |
| 9W3089 | HOUSING | 1 | |
| 9W0678 | CONTROL AS | 1 | |
| 5D6912 | DIODE-RECTIFIER | 21 | |
| 4P7581 | 19 CLIP (LADDER) | 1 | |
| 4V6981 | 20 SCREW-BUTTON HEAD (1/4-20X0.75-IN) | 4 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4136 | 22 BOLT (M10X1.5X25-MM) | 3 |
