System And Components
229-5583 LINES GP-AIR CONDITIONERS/N CXM1-UP
Group No: 229-5583
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P3928 | 1 COUPLING AS-REFRIGERANT (SELF-SEALING) | 1 | |
| 7K3176 | 2 COUPLING AS-REFRIGERANT (SELF-SEALING) | 1 | |
| 9M7961 | 3 FITTING | 2 | |
| 2030445 | 4 HOSE | 4 | |
| 2119330 | 5 GASKET | 1 | |
| 2135271 | 6 VALVE GP-CHECK (EVAPORATOR DRAIN) | 2 | |
| 2263697 | 7 BULKHEAD AS | 1 | |
| 2334932 | 8 HOSE AS | 1 | |
| 2334933 | 9 HOSE AS | 1 | |
| 2124174 | 10 LOCKWASHER | 1 | |
| 2H3924 | 11 LOCKWASHER | 1 | |
| 5P4106 | 12 NUT (1-7/16-16-THD) | 1 | |
| 7K3304 | 13 NUT-JAM (1-20-THD) | 1 | |
| 8T4189 | 14 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4224 | 15 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X7380 | 16 SEAL-O-RING | 1 | |
| 9X7382 | 17 SEAL-O-RING | 1 | |
| 9X7383 | 18 SEAL-O-RING | 1 | |
| 9X7384 | 19 SEAL-O-RING | 1 |
