System And Components
456-2125 WIRING GP-REARS/N 9SD1-UP
Group No: 456-2125
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W8795 | 1 BRACKET | 4 | |
| 3S2093 | 2 STRAP-CABLE | 51 | |
| 1160118 | 3 CLIP | 21 | |
| 1208234 | 4 BRACE | 2 | |
| 1952150 | 5 SENSOR GP-TEMPERATURE (ENGINE OIL) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 2106305 | 6 BRACKET | 1 | |
| 9X6258 | 7 SCREW-MACHINE (6-32X0.5-IN) | 8 | |
| 3840009 | 8 HARNESS AS-TRANSMISSION | 1 | |
| 3840010 | 9 HARNESS AS-REAR (CAB TO HITCH) | 1 | |
| 3840011 | 10 WIRE AS | 1 | |
| 3904996 | 11 BRACKET | 1 | |
| 3928092 | 12 PLATE | 1 | |
| 4505392 | 13 MOUNT AS | 1 | |
| 3904997 | BRACKET | 1 | |
| 5S0003 | NUT (5/16-18-THD) | 2 | |
| 4534118 | 14 MODULE AS | 1 | |
| 4562121 | 15 HARNESS AS-LIGHTING (REAR) | 1 | |
| 4562122 | 16 HARNESS AS-REAR (MAIN) | 1 | |
| 0338248 | 17 CLIP (LOOP) | 3 | |
| 0S0509 | 18 BOLT (3/8-16X0.75-IN) | 1 | |
| 1305300 | 19 CLIP | 10 | |
| 1336934 | 20 SPACER (11X20X25-MM THK) | 1 | |
| 1997854 | 21 SPACER (11.8X20X45-MM THK) | 1 | |
| 1S1015 | 22 CLIP (LOOP) | 1 | |
| 2147568 | 23 SEAL-O-RING | 1 | |
| 3979301 | 24 WASHER-HARD (11.5X20X15-MM THK) | 1 | |
| 2927180 | 25 GROMMET | 1 | |
| 2971546 | 26 CLIP | 1 | |
| 3065494 | 27 CLIP (LOOP) | 1 | |
| 3318540 | 28 CLIP (LOOP) | 2 | |
| 3368613 | 29 CLIP (LOOP) | 1 | |
| 3514318 | 30 CLIP (LOOP) | 1 | |
| 3D5279 | 31 GROMMET | 1 | |
| 4309455 | 32 SENSOR GP-LIQUID LEVEL (HYDROCARBON)(ENGINE OIL) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 1710596 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 4B5324 | 33 WASHER (3.9X9.6X1.2-MM THK) | 8 | |
| 4D7794 | 34 CLIP | 5 | |
| 4D8123 | 35 CLIP (LOOP) | 3 | |
| 4I5399 | 36 GROMMET | 2 | |
| 4K8864 | 37 CLIP (LOOP) | 1 | |
| 4L6454 | 38 BOLT (3/8-16X1-IN) | 12 | |
| 4L6459 | 39 BOLT (3/8-16X2.5-IN) | 5 | |
| 4L7124 | 40 BOLT (1/4-20X1.25-IN) | 2 | |
| 4P7581 | 41 CLIP (LADDER) | 1 | |
| 4W7627 | 42 SPACER (11X19X37-MM THK) | 6 | |
| 5M3062 | 43 BOLT (3/8-16X0.75-IN) | 7 | |
| 5P7854 | 44 CLIP (LOOP) | 5 | |
| 5P8167 | 45 BOLT (3/8-16X0.625-IN) | 1 | |
| 5P9085 | 46 CLIP (LOOP) | 3 | |
| 5S7379 | 47 BOLT (3/8-16X0.875-IN) | 19 | |
| 6D4244 | 48 CLIP (LOOP) | 2 | |
| 6V1889 | 49 CLIP (LOOP) | 2 | |
| 1367227 | 50 SEAL-O-RING | 1 | |
| 6V5839 | 51 WASHER (11X21X2.5-MM THK) | 6 | |
| 6V6317 | 52 BOLT (M10X1.5X20-MM) | 6 | |
| 6V8801 | 53 NUT (3/8-16-THD) | 11 | |
| 6V8918 | 54 BOLT (5/16-18X1.25-IN) | 2 | |
| 7D7233 | 55 CLIP (LOOP) | 3 | |
| 8M2773 | 56 CLIP (LOOP) | 9 | |
| 8T2501 | 57 BOLT (3/8-16X2-IN) | 1 | |
| 8T4205 | 58 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 8T4224 | 59 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4896 | 60 WASHER-HARD (10.2X18.5X2.5-MM THK) | 65 | |
| 8T4908 | 61 BOLT (M8X1.25X25-MM) | 2 | |
| 8T9364 | 62 BOLT (1/4-20X0.625-IN) | 4 | |
| 8T9371 | 63 BOLT (3/8-16X0.5-IN) | 2 | |
| 8T9377 | 64 BOLT (3/8-16X2.25-IN) | 2 | |
| 9B7237 | 65 BOLT (3/8-16X1.25-IN) | 2 | |
| 9X6165 | 66 WASHER (6.5X22X2.5-MM THK) | 1 | |
| 2856177 | 67 BLOCK-TAPPED | 1 |
