System And Components
262-7353 TANK & MTG GP-FUELS/N CXM1-UP
Group No: 262-7353
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1938252 | 1 SENDER AS-FUEL LEVEL (TANK) | 1 | |
| 6C3060 | GASKET | 1 | |
| 3634122 | GASKET | 1 | |
| 3761549 | KIT-DIAL SENSOR | 1 | |
| 2103556 | 2 COVER | 1 | |
| 5C9553 | 3 BOLT (M6X1X16-MM) | 12 | |
| 6C3060 | 4 GASKET | 2 | |
| 2741655 | 5 TANK AS-FUEL | 1 | |
| 2741656 | 6 TANK AS-FUEL | 1 | |
| 2741659 | 7 STEP AS | 2 | |
| 2741661 | 8 STEP AS | 1 | |
| 2741663 | 9 STEP AS | 1 | |
| 2741667 | 10 STEP AS | 2 | |
| 2741668 | 11 STEP AS | 1 | |
| 2741670 | 12 STEP AS | 1 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4123 | 14 WASHER (22X35X3.5-MM THK) | 24 | |
| 8T4131 | 15 NUT (M20X2.5-THD) | 8 | |
| 8T4139 | 16 BOLT (M12X1.75X30-MM) | 30 | |
| 8T4141 | 17 BOLT (M20X2.5X70-MM) | 8 | |
| 8T4183 | 18 BOLT (M12X1.75X40-MM) | 2 | |
| 8T4137 | 19 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 64 | |
| 8T4244 | 21 NUT (M12X1.75-THD) | 32 | |
| 8T6430 | 22 BOLT (M20X2.5X50-MM) | 8 | |
| 9X8256 | 23 WASHER (6.6X12X2-MM THK) | 12 | |
| 1160118 | 24 CLIP | 1 | |
| 8T4133 | 25 NUT (M10X1.5-THD) | 1 |
