System And Components
274-3263 SENSOR & MOUNTING GPS/N CXM1-UP
Group No: 274-3263
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4E2250 | 1 HOUSING | 1 | |
| 8C5607 | 2 MOUNT-ISOLATION | 6 | |
| 8C5608 | 3 SPACER (6.5X9.5X25.4-MM THK) | 3 | |
| 2661481 | 4 SENSOR GP-POSITION (TRAY UP) | 1 | |
| 1305300 | 5 CLIP | 1 | |
| 2106285 | 6 LEVER | 1 | |
| 2743267 | 7 MOUNT | 1 | |
| 2H3429 | 8 RING-RETAINING | 1 | |
| 2L6726 | 9 RING-RETAINING | 1 | |
| 4B4274 | 10 WASHER (5.5X13X1.2-MM THK) | 2 | |
| 4E2453 | 11 SHAFT | 1 | |
| 5C7261 | 12 NUT (M8X1.25-THD) | 2 | |
| 5P2675 | 13 BOLT (1/4-20X1.75-IN) | 3 | |
| 6D3025 | 14 BALL BEARING | 2 | |
| 6V2313 | 15 BOLT (M5X0.8X30-MM) | 2 | |
| 5P4115 | 16 WASHER-HARD (7.2X19X2-MM THK) | 3 | |
| 6V8185 | 17 NUT (1/4-20-THD) | 3 | |
| 7D9722 | 18 SPRING | 1 | |
| 7X2537 | 19 BOLT (M8X1.25X35-MM) | 1 | |
| 8T4121 | 20 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4136 | 21 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4205 | 22 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 8T4224 | 23 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 4M6425 | 24 BOLT (5/16-18X1-IN) | 1 |
