System And Components
207-2074 LINES GP-TRANSMISSION OILS/N CXM1-UP
Group No: 207-2074
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2111183 | 1 HOSE AS | 1 | |
| 2111184 | 2 HOSE AS | 1 | |
| 2111185 | 3 MANIFOLD | 1 | |
| 2111186 | 4 TUBE | 1 | |
| 2111187 | 5 TUBE | 1 | |
| 2111188 | 6 BRACKET | 1 | |
| 1731437 | 7 FLANGE-HALF | 6 | |
| 1P4579 | 8 FLANGE-HALF | 2 | |
| 3J1907 | 9 SEAL-O-RING | 2 | |
| 4J0522 | 10 SEAL-O-RING | 5 | |
| 4J0524 | 11 SEAL-O-RING | 2 | |
| 5J5793 | 12 BOLT-12 POINT HEAD (1/2-13X2-IN) | 4 | |
| 5P1075 | 13 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 5P2566 | 14 BOLT (1/2-13X1.5-IN) | 4 | |
| 5P7470 | 15 CLIP (SLOT) | 2 | |
| 5P7471 | 16 CLIP (TAB) | 2 | |
| 5P8182 | 17 GROMMET (46-MM ID) | 2 | |
| 6L1648 | 18 SEAL-O-RING | 2 | |
| 6V0852 | 19 CAP-DUST | 2 | |
| 6V3965 | 20 FITTING (QUICK DISCONNECT) | 2 | |
| 7G3413 | 21 CLIP (SLOT) | 1 | |
| 7G3414 | 22 CLIP (TAB) | 1 | |
| 7G3415 | 23 GROMMET | 1 | |
| 7M8485 | 24 SEAL-O-RING | 1 | |
| 7X0312 | 25 BOLT (7/16-14X2.5-IN) | 8 | |
| 8S0023 | 26 CLIP (SLOT) | 2 | |
| 8S0024 | 27 CLIP (TAB) | 2 | |
| 8T4133 | 28 NUT (M10X1.5-THD) | 2 | |
| 8T4195 | 29 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T4956 | 31 BOLT (M12X1.75X35-MM) | 12 | |
| 8T5360 | 32 WASHER (12X22.5X2.5-MM THK) | 16 | |
| 8T8916 | 33 BOLT (7/16-14X1.5-IN) | 8 | |
| 9S4181 | 34 PLUG (1-5/16-12-THD) | 1 |
