System And Components
137-2110 PLANETARY GP-TRANSMISSIONS/N MRB602-UP
Group No: 137-2110
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7T7771 | 1 CARRIER-PLANETARY | 1 | |
| 6L4783 | 2 BOLT-12 POINT HEAD (5/16-18X1.25-IN) | 4 | |
| 8E3610 | 3 RETAINER | 1 | |
| 7G1141 | 4 SHAFT-CENTER | 1 | |
| 8D8621 | 5 RING-RETAINING | 1 | |
| 1764114 | 6 CARRIER AS | 1 | |
| 6F6547 | 6A BUSHING | 1 | |
| 8E8307 | 7 DISC-THRUST | 8 | |
| 7G0747 | 8 SHAFT AS | 4 | |
| 2A3746 | PLUG-CUP | 1 | |
| 3S2708 | 9 PIN-SPRING | 18 | |
| 5M0578 | 10 BEARING AS-ROLLER | 8 | |
| 2244826 | 11 GEAR-PLANETARY (21-TEETH) | 4 | |
| 1332968 | 12 GEAR-RING (85-TEETH) | 1 | |
| 1406669 | 13 COVER AS | 1 | |
| 4B9880 | BALL | 1 | |
| 8D4771 | 14 SEAL-O-RING | 2 | |
| 1332972 | 15 HOUSING AS | 1 | |
| 1A2223 | DOWEL | 2 | |
| 6T1996 | 16 PLATE-CLUTCH | 9 | |
| 1329643 | 17 PISTON-CLUTCH | 2 | |
| 3P2795 | 18 SEAL-RING | 4 | |
| 7G1186 | 19 RING-SEAL (EXTERNAL) | 2 | |
| 7G1596 | 20 RING-RETAINING | 1 | |
| 7G0746 | 21 SHAFT AS | 4 | |
| 5M7921 | PLUG-CORE | 1 | |
| 9M4355 | 22 DAMPER-BOLT | 10 | |
| 5P9345 | 23 BEARING | 8 | |
| 2244825 | 24 GEAR-PLANETARY (20-TEETH) | 4 | |
| 8E8306 | 25 DISC-THRUST | 8 | |
| 3T0698 | 26 HOUSING-CLUTCH | 1 | |
| 8P8744 | 27 RING-SEAL EXTENSION | 2 | |
| 5P9362 | 28 RING-RETAINING | 1 | |
| 7G0825 | 29 PLATE-CLUTCH | 3 | |
| 5M6126 | 30 BEARING AS-ROLLER | 13 | |
| 7G2516 | 31 GEAR-PLANETARY (24-TEETH) | 4 | |
| 8E8304 | 32 DISC-THRUST | 26 | |
| 7G0721 | 33 SHAFT-PLANETARY | 4 | |
| 2219685 | 34 DISC-FRICTION | 5 | |
| 7G0824 | 35 PLATE-CLUTCH | 4 | |
| 1T0141 | 36 RING-METAL SEAL | 1 | |
| 2L0043 | 37 RING-RETAINING | 1 | |
| 1067799 | 38 BALL BEARING | 2 | |
| 1A2170 | 39 SPRING-RETAINER | 28 | |
| 3T2299 | 40 RING-SEAL EXTENSION | 2 | |
| 6Y2281 | 41 RING-SEAL | 2 | |
| 1S0579 | 42 BALL BEARING | 1 | |
| 6Y5888 | 43 RING-SEAL | 2 | |
| 3T3725 | 44 RING-SEAL EXTENSION | 2 | |
| 8S3370 | 45 RING-SEAL | 1 | |
| 3P0896 | 46 RING-RETAINING | 2 | |
| 5L4753 | 47 RING-RETAINING | 2 | |
| 6V4323 | 48 BALL BEARING | 1 | |
| 5M6212 | 49 TUBE | 3 | |
| 7G0719 | 50 SHAFT-PLANETARY | 3 | |
| 8P2051 | 51 PLATE-CLUTCH | 1 | |
| 9P7390 | 52 DISC AS-FRICTION | 2 | |
| 8E9599 | 53 PISTON-CLUTCH | 1 | |
| 9W8575 | 54 HOUSING AS-CLUTCH | 1 | |
| 1A2223 | DOWEL | 2 | |
| 8P2022 | 55 RING-SEAL | 1 | |
| 8P9569 | 56 RING-SEAL | 1 | |
| 9W8571 | 57 HUB AS | 1 | |
| 9M2001 | DOWEL | 1 | |
| 8E9600 | 58 CAGE-BEARING | 1 | |
| 8E9601 | 59 MANIFOLD | 1 | |
| 7G2476 | 60 GEAR-PLANETARY (20-TEETH) | 6 | |
| 5P6727 | 61 BALL BEARING | 1 | |
| 5P5296 | 62 RING-RETAINING | 1 | |
| 3T7000 | 63 RING-RETAINING | 1 | |
| 3T6999 | 64 GEAR-SUN (30, 26-TEETH) | 1 | |
| 0S1588 | 65 BOLT (3/8-16X1.25-IN) | 40 | |
| 5M2894 | 66 WASHER-HARD (10.2X18.5X2.5-MM THK) | 51 | |
| 7G0720 | 67 SHAFT-PLANETARY | 3 | |
| 2B0947 | 68 BOLT (1/2-13X2.25-IN) | 8 | |
| 5P8245 | 69 WASHER-HARD (13.5X25.5X3-MM THK) | 38 | |
| 7G0725 | 70 GEAR-RING (72-TEETH) | 1 | |
| 1A7669 | 71 BOLT (1/2-13X7-IN) | 8 | |
| 3D9348 | 72 BOLT (1/2-13X7.75-IN) | 2 | |
| 4M8871 | 73 DOWEL | 10 | |
| 4M9592 | 74 SPRING | 20 | |
| 3073850 | 75 HOUSING-CLUTCH | 1 | |
| 9H5545 | 76 DOWEL-REACTION | 5 | |
| 7G0731 | 77 PISTON-CLUTCH | 2 | |
| 7M5813 | 78 SPRING | 10 | |
| 8E3602 | 79 CARRIER AS | 1 | |
| 3T7003 | 79A BUSHING | 1 | |
| 7G1143 | 80 GEAR AS (73-TEETH) | 1 | |
| 9M2001 | DOWEL | 1 | |
| 3T0707 | 81 PLATE AS | 2 | |
| 5H6202 | PIN | 2 | |
| 7G2475 | 82 GEAR-PLANETARY (24-TEETH) | 3 | |
| 8P2053 | 83 SEAL-RING | 1 | |
| 9F3823 | 84 RING-SEAL | 2 | |
| 9W9158 | 85 PISTON-BALANCE | 1 | |
| 9W9159 | 86 PISTON-CLUTCH | 1 | |
| 9W9161 | 87 HOUSING AS | 1 | |
| 6B6863 | PIN-SPRING | 1 | |
| 6P7706 | CARRIER-RING | 1 | |
| 8M6521 | DOWEL | 2 | |
| 8S3426 | DOWEL | 1 | |
| 3T0697 | 88 MANIFOLD-CENTER | 1 | |
| 0S1571 | 89 BOLT (3/8-16X1.75-IN) | 9 | |
| 8E9292 | 90 MANIFOLD AS | 1 | |
| 8S3426 | DOWEL | 1 | |
| 7G0739 | 91 HOUSING AS | 1 | |
| 8M6521 | DOWEL | 2 | |
| 0616712 | 92 RING-RETAINING | 1 | |
| 4S5816 | 93 RING-SEAL | 1 | |
| 3T3751 | 94 PISTON-CLUTCH | 1 | |
| 5P0076 | 95 BOLT-12 POINT HEAD (3/8-16X1.5-IN) | 6 | |
| 3T3723 | 96 PISTON-BALANCE | 1 | |
| 0L1351 | 97 BOLT (3/8-16X0.875-IN) | 2 | |
| 3T3997 | 98 BAFFLE AS | 1 | |
| 5C1014 | BRACKET-LATCH | 2 | |
| 7G1146 | 99 GEAR AS-SUN (55-TEETH) | 1 | |
| 9M2001 | DOWEL | 1 | |
| 7G0713 | 100 CARRIER AS | 1 | |
| 9L9068 | DOWEL | 2 | |
| 7G0727 | 101 GEAR-RING (101-TEETH) | 1 | |
| 9F3788 | 102 RING-METAL SEAL | 1 | |
| 1649661 | 103 HOUSING AS | 1 | |
| 1A2223 | DOWEL | 4 | |
| 0S1617 | 104 BOLT (5/16-18X0.75-IN) | 4 | |
| 1B7182 | 105 BOLT (5/16-18X1.25-IN) | 2 | |
| 9M1974 | 106 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 7G0743 | 107 PLATE | 1 | |
| 9M1503 | 108 RING-METAL SEAL | 1 | |
| 1M9691 | 109 SPRING | 10 | |
| 1649662 | 110 DOWEL-REACTION | 5 | |
| 1332969 | 111 GEAR-RING (85-TEETH) | 1 | |
| 4M1678 | 112 SPRING | 10 | |
| 1358685 | 113 PIN | 10 | |
| 1D4574 | 114 BOLT (1/2-13X6-IN) | 10 | |
| 4M9641 | 115 BOLT (1/2-13X12.75-IN) | 10 | |
| 7G0744 | 116 PLATE-RETAINER | 1 | |
| 1T0720 | 117 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 4 | |
| 7G1148 | 118 GEAR-SUN (30-TEETH) | 1 | |
| 7G1136 | 119 GEAR AS-SUN (29-TEETH) | 1 | |
| 7G1137 | GEAR-SUN (29-TEETH) | 1 | |
| 7G1138 | HUB-COUPLING | 1 | |
| 9S2843 | RING-LOCK | 1 | |
| 1028671 | 120 DISC-FRICTION | 16 | |
| 1717209 | 121 RING-SEAL | 1 |
