System And Components
259-3970 CYLINDER GP-STEERINGS/N CXM1-UP
Group No: 259-3970
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2593969 | 1 CYLINDER AS | 1 | |
| 7J9346 | 1A BEARING-SLEEVE | 1 | |
| 5M6214 | PLUG (1/8-27 PTF) | 2 | |
| 8T8394 | 2 RING-WEAR | 1 | |
| 5J5731 | 3 LOCKNUT (1-3/4-12-THD) | 1 | |
| 4J3420 | 4 RING-WEAR | 1 | |
| 5J5020 | 5 SEAL AS | 1 | |
| 5J4973 | RING-EXPANDER | 1 | |
| 5J4974 | SEAL | 1 | |
| 2117933 | 6 PISTON | 1 | |
| 2K4096 | 7 RING-BACKUP | 1 | |
| 3016477 | 8 GLAND | 1 | |
| 2892937 | 9 SEAL AS-BUFFER | 1 | |
| 2892948 | 10 SEAL-U-CUP | 1 | |
| 2253281 | 11 SEAL-WIPER | 1 | |
| 2781519 | 12 ROD AS | 1 | |
| 7J9346 | 12A BEARING-SLEEVE | 1 | |
| 3B8489 | FITTING-GREASE (1/8-27 PTF) | 1 | |
| 5F3144 | 13 SEAL-O-RING | 1 | |
| 8T4171 | 14 BOLT (M6X1X12-MM) | 3 | |
| 9X8256 | 15 WASHER (6.6X12X2-MM THK) | 3 | |
| 8T4141 | 16 BOLT (M20X2.5X70-MM) | 4 | |
| 8T4123 | 17 WASHER (22X35X3.5-MM THK) | 4 | |
| 1636223 | KIT-SEAL (STEERING CYLINDER) | 1 |
