System And Components
268-2506 LINES GP-AIR CONDITIONERS/N CXM567-UP
Group No: 268-2506
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2682512 | 1 HOSE AS | 1 | |
| 2682513 | 2 HOSE AS | 1 | |
| 2682514 | 3 HOSE AS | 1 | |
| 6D2667 | 4 CLIP | 6 | |
| 1140069 | 5 PLATE-INSTRUCTION (AIR CONDITIONER) | 1 | |
| 9X7382 | 6 SEAL-O-RING | 1 | |
| 8T4196 | 7 BOLT (M10X1.5X35-MM) | 3 | |
| 2533566 | 8 HOSE AS | 1 | |
| 5K5338 | 9 CLIP (LOOP) | 5 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 18 | |
| 9X7380 | 11 SEAL-O-RING | 3 | |
| 8T4136 | 12 BOLT (M10X1.5X25-MM) | 9 | |
| 2P4556 | 13 CLIP | 2 | |
| 1065534 | 14 DRYER-REFRIGERANT (RECEIVER) | 1 | |
| 1K4649 | 15 SPACER (0.516X1X1-IN THK) | 2 | |
| 3S2093 | 16 STRAP-CABLE | 1 | |
| 8T4133 | 18 NUT (M10X1.5-THD) | 4 | |
| 5P3929 | 19 COUPLING AS-REFRIGERANT (SELF-SEALING) | 1 | |
| 5P3944 | 21 SEAL-O-RING | 1 | |
| 9X7383 | 23 SEAL-O-RING | 1 | |
| 5P3948 | 24 COUPLING AS-REFRIGERANT (SELF-SEALING) | 1 | |
| 9X7381 | 25 SEAL-O-RING | 2 | |
| 9X7385 | 26 SEAL-O-RING | 2 | |
| 2069762 | 27 FITTING AS-AIR CONDITIONER | 1 | |
| 3E4051 | CAP-SEAL (LOW SIDE CHARGE PORT) | 1 | |
| 3E4057 | VALVE AS (REFRIGERANT, LOW SIDE) | 1 | |
| 3514945 | 28 FITTING AS-AIR CONDITIONER | 1 | |
| 3E4052 | CAP-SEAL (HIGH SIDE CHARGE PORT) | 1 | |
| 3E4058 | VALVE AS (REFRIGERANT, HIGH SIDE) | 1 | |
| 1P6356 | 29 PLATE | 1 | |
| 8T6466 | 30 BOLT (M10X1.5X60-MM) | 1 | |
| 8T7934 | 31 WASHER-HARD (11X21X5-MM THK) | 1 | |
| 9M8406 | 32 CLIP (LOOP) | 1 | |
| 8T4185 | 33 BOLT (M10X1.5X50-MM) | 2 | |
| 1S9593 | 34 STRAP-CABLE | 2 | |
| 1174473 | 35 SEAL (32-CM) |
