System And Components
338-6589 WIRING GP-PAYLOADS/N GXM1-UP
Group No: 338-6589
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1160118 | 1 CLIP | 1 | |
| 1196105 | 2 GROMMET | 1 | |
| 2471625 | 3 ANTENNA | 1 | |
| 2471629 | 4 HARNESS AS-CAB (HITCH) | 1 | |
| 2471630 | 5 HARNESS AS-CAB (PAYLOAD) | 1 | |
| 2471631 | 6 HARNESS AS-PANEL (PAYLOAD, DISPLAY) | 1 | |
| 2471632 | 7 LAMP GP-PAYLOAD SIGNAL (PAYLOAD) | 2 | |
| 2471633 | 8 HARNESS AS-MONITOR (REMOTE) | 1 | |
| 3004797 | PLUG | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | ||
| 2471634 | 9 TRANSMITTER | 1 | |
| 2471635 | 10 PLATE AS | 1 | |
| 7T1099 | LINK | 1 | |
| 2532736 | 11 HARNESS AS-MONITOR (TRAILER) | 1 | |
| 1305300 | 12 CLIP | 2 | |
| 1538001 | 13 BOLT-SOCKET HEAD (M4X0.7X20-MM) | 2 | |
| 4P8134 | 14 CLIP (LADDER) | 1 | |
| 5C8312 | 15 NUT (M4X0.7-THD) | 2 | |
| 6K0806 | 16 STRAP-CABLE | 76 | |
| 6V7743 | 17 LOCKNUT (M6X1-THD) | 4 | |
| 7G7053 | 18 GROMMET | 1 | |
| 8S0023 | 19 CLIP (SLOT) | 2 | |
| 8S0024 | 20 CLIP (TAB) | 2 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4133 | 22 NUT (M10X1.5-THD) | 3 | |
| 8T4136 | 23 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4186 | 24 BOLT (M10X1.5X40-MM) | 1 | |
| 8T9471 | 25 GROMMET | 1 | |
| 9C5344 | 26 SPACER (10.5X20X18-MM THK) | 1 | |
| 9X2046 | 27 SCREW-TRUSS HEAD (M6X1X35-MM) | 4 | |
| 9X2480 | 28 BOLT (M6X1X45-MM) | 4 | |
| 9X8256 | 29 WASHER (6.6X12X2-MM THK) | 8 |
