System And Components
385-9820 SHAFT GP-DRIVES/N CXM489-UP
Group No: 385-9820
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8D9558 | 1 RIVET | 2 | |
| 2072116 | 2 SHAFT GP-DRIVE (FRONT AXLE) | 1 | |
| 2098849 | 3 SLIP JOINT GP | 1 | |
| 2111870 | 4 MOUNT AS | 1 | |
| 2170449 | 5 FLAP | 1 | |
| 2551573 | 6 SHAFT GP-DRIVE (UPPER) | 1 | |
| 2597167 | 7 SHAFT GP-DRIVE (REAR AXLE) | 1 | |
| 2618405 | 8 SHAFT GP-DRIVE (OSCILLATION) | 1 | |
| 2835321 | 9 GUARD AS | 1 | |
| 9R2672 | BOSS-THREADED (M10X1.5X20-MM) | 1 | |
| 3033572 | 10 STRIP | 1 | |
| 4528557 | 11 GUARD AS | 1 | |
| 2111866 | 12 GUARD | 1 | |
| 2111869 | 13 SPACER | 2 | |
| 2835323 | 14 GUARD | 1 | |
| 3H7654 | 15 WASHER-HARD (13.5X22.5X3-MM THK) | 8 | |
| 4L6454 | 16 BOLT (3/8-16X1-IN) | 4 | |
| 5P8245 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6V3823 | 18 BOLT (M12X1.75X60-MM) | 8 | |
| 8T0281 | 19 BOLT (M16X2X80-MM) | 24 | |
| 8T2501 | 20 BOLT (3/8-16X2-IN) | 4 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4140 | 22 BOLT (M16X2X60-MM) | 2 | |
| 8T4195 | 23 BOLT (M10X1.5X30-MM) | 6 | |
| 8T4896 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 9X8257 | 25 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 9X8268 | 26 WASHER (17.5X30X3.5-MM THK) | 24 | |
| 9X8878 | 27 BOLT (1/2-13X5.25-IN) | 4 | |
| 4528558 | 28 GUARD | 1 | |
| 8T0389 | 29 LOCKNUT (M10X1.5-THD) | 4 |
