277-3372 LINES GP-SECONDARY STEERINGS/N CXM1-539

Group No: 277-3372

Part Number	Part Name	Qty
4J0524	1 SEAL-O-RING	13
2117355	2 TUBE AS	1
8T4223	3 WASHER-HARD (13.5X25.5X3-MM THK)	48
1P4579	4 FLANGE-HALF	22
2169799	5 HOSE AS	1
5P7464	6 CLIP (SLOT)	2
5P7465	7 CLIP (TAB)	2
8S0023	8 CLIP (SLOT)	1
2117357	9 HOSE AS	1
6V8635	10 CONNECTOR	1
5K9090	11 SEAL-O-RING	1
2117358	12 MANIFOLD	1
4J0523	13 SEAL-O-RING	1
8T8919	14 BOLT (1/2-13X1.75-IN)	16
2672289	15 HOSE AS	1
8T4244	16 NUT (M12X1.75-THD)	3
8T4121	17 WASHER-HARD (11X21X2.5-MM THK)	8
7G3414	18 CLIP (TAB)	2
7G3413	19 CLIP (SLOT)	2
8T4184	20 BOLT (M12X1.75X45-MM)	12
8T4196	21 BOLT (M10X1.5X35-MM)	4
2117362	22 HOSE AS	1
7M8485	23 SEAL-O-RING	1
8C3206	24 FLANGE-HALF	2
2521968	25 HOSE AS	1
4J0520	26 SEAL-O-RING	2
8T4956	27 BOLT (M12X1.75X35-MM)	6
2172348	28 HOSE AS	1
8S0024	29 CLIP (TAB)	1
8T6466	30 BOLT (M10X1.5X60-MM)	4
2117354	31 TUBE AS	1
2117363	32 TUBE AS	1
6V1324	33 GROMMET	2
5P2566	34 BOLT (1/2-13X1.5-IN)	20
3E6429	35 SWITCH AS-FLOW (SECONDARY STEERING)	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	2
1028802	KIT-RECEPTACLE (2-PIN)	1
9X1813	SLEEVE (20-CM)
3K0360	36 SEAL-O-RING	1
2295610	37 MANIFOLD	1
7X0325	38 BOLT (1/2-13X2.5-IN)	4
2117356	39 HOSE AS	1
8T4192	40 BOLT (M12X1.75X25-MM)	2
5P1076	41 WASHER-HARD (13.5X30X4-MM THK)	2
2117359	42 MOUNT	1
2191500	43 MANIFOLD	1
8T4910	44 BOLT (M12X1.75X60-MM)	1
8T9391	45 BOLT (1/2-13X3.75-IN)	4
1P4582	46 FLANGE-HALF	2
4J0527	47 SEAL-O-RING	2
2S4078	48 SEAL-O-RING	1
9S6130	49 PLUG	1
1V8230	50 SPACER (0.531X1X0.57-IN THK)	1
