System And Components
8T-7413 STRINGLINE GPS/N 1JG1-UP
Group No: 8T-7413
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1C4487 | 1 TUBE | 2 | |
| 9B7237 | 2 BOLT (3/8-16X1.25-IN) | 84 | |
| 8C7809 | 3 COLLAR | 4 | |
| 0817764 | 4 LINK | 1 | |
| 0817766 | 5 BRACKET | 2 | |
| 1095638 | 6 TUBE | 1 | |
| 7X0278 | 7 BOLT (5/16-18X4-IN) | 16 | |
| 8T4224 | 8 WASHER-HARD (8.8X16X2-MM THK) | 16 | |
| 1097801 | 9 BRACKET AS | 2 | |
| 0817770 | 10 BEAM | 3 | |
| 0817769 | 11 BEAM-END | 4 | |
| 8T4896 | 12 WASHER-HARD (10.2X18.5X2.5-MM THK) | 84 | |
| 0817768 | 13 BEAM-END | 2 | |
| 9N8909 | 14 STRINGLINE | 1 | |
| 6V8801 | 15 NUT (3/8-16-THD) | 84 | |
| 0817524 | 16 PIN-HITCH | 8 | |
| 0817765 | 17 GUIDE | 1 | |
| 0817212 | 18 GUIDE | 1 | |
| 0817767 | 19 BRACKET | 4 | |
| 6V8189 | 20 NUT (5/16-18-THD) | 16 | |
| 0819630 | 21 BRACKET | 1 | |
| 0817209 | 22 BRACKET | 12 | |
| 7X0334 | 23 BOLT (1/2-13X5-IN) | 8 | |
| 0817211 | 24 SHOE-PAN | 8 | |
| 2H3788 | 25 LOCKNUT (1/2-13-THD) | 8 | |
| 0819638 | 26 CHANNEL | 4 |
