System And Components
105-2282 PUMP GP-PISTONS/N 1ZN1-UP; 2TN1-UP
Group No: 105-2282
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1G8639 | 1 SEAL-O-RING | 1 | |
| 1152158 | 2 RING-PILOT | 1 | |
| 7X5466 | 3 NUT | 1 | |
| 3D2824 | 4 SEAL-O-RING | 3 | |
| 1176507 | 5 VALVE-RELIEF | 1 | |
| 0304008 | 6 SPRING | 1 | |
| 0773775 | 7 SHIM | 1 | |
| 2M9780 | 8 SEAL-O-RING | 2 | |
| 7X5462 | 9 PLUG | 1 | |
| 1H1023 | 10 SEAL-O-RING | 2 | |
| 7X5454 | 11 RING-BACKUP | 2 | |
| 7X9365 | 12 VALVE-BYPASS | 1 | |
| 9S8010 | 13 PLUG | 1 | |
| 2S4078 | 14 SEAL-O-RING | 1 | |
| 7X5442 | 15 STOP | 1 | |
| 7X5443 | 16 SPRING | 1 | |
| 7X5441 | 17 GUIDE | 1 | |
| 7X5444 | 18 BOLT | 1 | |
| 7X5498 | 19 GASKET | 2 | |
| 9S4191 | 20 PLUG (9/16-18-THD) | 4 | |
| 3J1907 | 21 SEAL-O-RING | 4 | |
| 1G8494 | 22 BOLT (1/4-20X1.125-IN) | 10 | |
| 7X5439 | 23 COVER | 1 | |
| 1152157 | 24 PIN | 1 | |
| 1081753 | 25 BEARING | 2 | |
| 7X5450 | 26 PISTON-SERVO | 1 | |
| 7X5445 | 27 GUIDE | 1 | |
| 7X5446 | 28 RING-RETAINING | 1 | |
| 6V8183 | 29 NUT-FULL (3/8-24-THD) | 1 | |
| 5B9079 | 30 NUT-JAM (3/8-24-THD) | 1 | |
| 5J5793 | 31 BOLT-12 POINT HEAD (1/2-13X2-IN) | 2 | |
| 7X5478 | 32 PIN-SPRING | 1 | |
| 7X5486 | 33 GASKET | 1 | |
| 7X5468 | 34 BEARING AS-NEEDLE | 1 | |
| 1178295 | 35 PLATE-VALVE | 1 | |
| 7X5469 | 36 RING-RETAINING | 1 | |
| 7X5470 | 37 WASHER-SPECIAL | 1 | |
| 7X5471 | 38 SPRING | 1 | |
| 7X5472 | 39 WASHER (31.2X40.3X2.7-MM THK) | 1 | |
| 7X5497 | 40 CYLINDER BLOCK | 1 | |
| 7X5474 | 41 PIN | 1 | |
| 7X5473 | 42 RETAINER | 1 | |
| 7X5477 | 43 GUIDE-RETAINER | 1 | |
| 1G5975 | 44 GUIDE | 1 | |
| 1G5974 | 45 PISTON | 7 | |
| 1152156 | 46 SHAFT-PUMP | 1 | |
| 1389753 | 47 PIN-SLOTTED | 1 | |
| 7X5431 | 48 KIT-SWASHPLATE | 1 | |
| 1248349 | 49 PIN | 2 | |
| 1248343 | 50 BEARING-JOURNAL | 2 | |
| 0344288 | 51 BOLT-12 POINT HEAD (3/8-16X1.125-IN) | 1 | |
| 8H9789 | 52 BALL BEARING | 1 | |
| 1J6474 | 53 RING-RETAINING | 2 | |
| 2H5549 | 54 RING-RETAINING | 2 | |
| 7X5433 | 55 SEAL-LIP TYPE | 1 | |
| 5P2547 | 56 BOLT-12 POINT HEAD (7/16-14X1-IN) | 6 | |
| 7X5484 | 57 PIN | 1 | |
| 7X5485 | 58 BUSHING | 1 | |
| 7X5489 | 60 PIN | 1 | |
| 7X5440 | 61 COVER | 1 | |
| 9S8008 | 62 PLUG (1-1/16-12-THD) | 2 | |
| 1176506 | 63 PLUG-ORIFICE | 1 | |
| 9F2247 | 64 PLUG-PIPE (1/8-27-THD) | 2 | |
| 7X5460 | 65 SLEEVE | 1 | |
| 7X5457 | 66 SPRING | 1 | |
| 7X5459 | 67 BRACKET | 1 | |
| 7X5458 | 68 HANDLE | 1 | |
| 2R0504 | 69 NUT (5/16-18-THD) | 1 | |
| 7H3937 | 70 LOCKWASHER | 1 | |
| 0822753 | 71 BOLT (1/4-20X0.62-IN) | 1 | |
| 7X9367 | 72 SPOOL | 1 | |
| 7X5453 | 73 RING-BACKUP | 1 | |
| 4D2297 | 74 SEAL-O-RING | 1 | |
| 4M6425 | 75 BOLT (5/16-18X1-IN) | 3 | |
| 9S8006 | 76 PLUG (7/8-14-THD) | 1 | |
| 1G9411 | 77 ADAPTER | 1 | |
| 1G9412 | 78 GASKET | 1 | |
| 7X5490 | 79 COUPLING | 1 | |
| 1152160 | 84 FLANGE | 1 | |
| 3D2824 | 85 SEAL-O-RING | 4 | |
| 1H1023 | 86 SEAL-O-RING | 2 | |
| 7X5454 | 87 RING-BACKUP | 2 | |
| 7X9365 | 88 VALVE-BYPASS | 1 | |
| 7X5442 | 89 STOP | 1 | |
| 7X5443 | 90 SPRING | 1 | |
| 7X5441 | 91 GUIDE | 1 | |
| 7X5444 | 92 BOLT | 1 | |
| 7X5498 | 93 GASKET | 2 | |
| 9S4191 | 94 PLUG (9/16-18-THD) | 4 | |
| 3J1907 | 95 SEAL-O-RING | 4 | |
| 1G8494 | 96 BOLT (1/4-20X1.125-IN) | 10 | |
| 7X5439 | 97 COVER | 1 | |
| 1092981 | 98 PLATE-VALVE | 1 | |
| 1081753 | 99 BEARING | 2 | |
| 7X5450 | 100 PISTON-SERVO | 1 | |
| 7X5445 | 101 GUIDE | 1 | |
| 7X5446 | 102 RING-RETAINING | 1 | |
| 6V8183 | 103 NUT-FULL (3/8-24-THD) | 1 | |
| 5B9079 | 104 NUT-JAM (3/8-24-THD) | 1 | |
| 7X5478 | 105 PIN-SPRING | 1 | |
| 7X5486 | 106 GASKET | 1 | |
| 7X5468 | 107 BEARING AS-NEEDLE | 1 | |
| 7X5469 | 108 RING-RETAINING | 1 | |
| 7X5470 | 109 WASHER-SPECIAL | 1 | |
| 7X5471 | 110 SPRING | 1 | |
| 7X5472 | 111 WASHER (31.2X40.3X2.7-MM THK) | 1 | |
| 7X5497 | 112 CYLINDER BLOCK | 1 | |
| 7X5474 | 113 PIN | 1 | |
| 7X5473 | 114 RETAINER | 1 | |
| 7X5477 | 115 GUIDE-RETAINER | 1 | |
| 1G5975 | 116 GUIDE | 1 | |
| 1G5974 | 117 PISTON | 1 | |
| 1389753 | 118 PIN-SLOTTED | 1 | |
| 7X5431 | 119 KIT-SWASHPLATE | 1 | |
| 1248349 | 120 PIN | 2 | |
| 1248343 | 121 BEARING-JOURNAL | 2 | |
| 0344288 | 122 BOLT-12 POINT HEAD (3/8-16X1.125-IN) | 1 | |
| 8H9789 | 123 BALL BEARING | 1 | |
| 1J6474 | 124 RING-RETAINING | 1 | |
| 2H5549 | 125 RING-RETAINING | 1 | |
| 5P2547 | 126 BOLT-12 POINT HEAD (7/16-14X1-IN) | 6 | |
| 7X5484 | 127 PIN | 1 | |
| 7X5485 | 128 BUSHING | 1 | |
| 7X5489 | 130 PIN | 1 | |
| 7X5440 | 131 COVER | 1 | |
| 9S8008 | 132 PLUG (1-1/16-12-THD) | 2 | |
| 1176506 | 133 PLUG-ORIFICE | 1 | |
| 9F2247 | 134 PLUG-PIPE (1/8-27-THD) | 2 | |
| 7X5460 | 135 SLEEVE | 1 | |
| 7X5457 | 136 SPRING | 1 | |
| 7X5459 | 137 BRACKET | 1 | |
| 7X5458 | 138 HANDLE | 1 | |
| 2R0504 | 139 NUT (5/16-18-THD) | 1 | |
| 7H3937 | 140 LOCKWASHER | 1 | |
| 0822753 | 141 BOLT (1/4-20X0.62-IN) | 1 | |
| 7X9367 | 142 SPOOL | 1 | |
| 7X5453 | 143 RING-BACKUP | 1 | |
| 4D2297 | 144 SEAL-O-RING | 1 | |
| 7X9372 | 145 SEAL-O-RING | 1 | |
| 7X9373 | 146 SEAL-O-RING | 1 | |
| 1152159 | 147 SHAFT-PUMP | 1 | |
| 6V3922 | 148 SEAL-O-RING | 2 | |
| 7X5466 | 149 NUT | 1 | |
| 7X5492 | 150 STUD | 1 | |
| 1F7958 | 151 NUT-FULL (1/2-13-THD) | 1 | |
| 9X0803 | KIT-VALVE | 1 | |
| 7X5866 | KIT-CYLINDER BLOCK (PROPEL MOTOR) | 1 | |
| 7X5448 | KIT-PISTON RING | 1 |
