System And Components
148-8257 PUMP GP-PISTONS/N 6EN151-UP
Group No: 148-8257
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9S8004 | 1 PLUG (9/16-18-THD) | 2 | |
| 3J1907 | 2 SEAL-O-RING | 5 | |
| 3D2824 | 3 SEAL-O-RING | 2 | |
| 9S9334 | 5 PLUG (1-5/16-12-THD) | 1 | |
| 1696687 | 6 NUT | 1 | |
| 3S2713 | 7 NUT-FULL (3/8-24-THD) | 1 | |
| 7X5446 | 8 RING-RETAINING | 1 | |
| 7X5445 | 9 GUIDE | 1 | |
| 7X5442 | 10 STOP | 1 | |
| 7X5443 | 11 SPRING | 1 | |
| 1805086 | 12 GUIDE-SPRING | 1 | |
| 1805107 | 13 SCREW-SPECIAL | 1 | |
| 1G8494 | 14 BOLT (1/4-20X1.125-IN) | 10 | |
| 9S4191 | 15 PLUG (9/16-18-THD) | 6 | |
| 7R5517 | 16 BRACKET-LIFTING | 1 | |
| 7X5439 | 17 COVER | 1 | |
| 7X5498 | 18 GASKET | 2 | |
| 4L7711 | 20 SEAL-O-RING | 2 | |
| 1081753 | 21 BEARING | 2 | |
| 7X5450 | 22 PISTON-SERVO | 1 | |
| 7X9365 | 23 VALVE-BYPASS | 1 | |
| 7X5454 | 24 RING-BACKUP | 2 | |
| 1H1023 | 25 SEAL-O-RING | 2 | |
| 7X5462 | 26 PLUG | 1 | |
| 2M9780 | 27 SEAL-O-RING | 2 | |
| 0773775 | 28 SHIM | 1 | |
| 1616576 | 29 SPRING | 1 | |
| 1176507 | 30 VALVE-RELIEF | 1 | |
| 3J7354 | 31 SEAL-O-RING | 1 | |
| 1178294 | 32 SHAFT-PUMP | 1 | |
| 1389753 | 33 PIN-SLOTTED | 1 | |
| 7X5484 | 34 PIN | 1 | |
| 1248349 | 36 PIN | 2 | |
| 1248343 | 37 BEARING-JOURNAL | 2 | |
| 1254660 | 38 BOLT-TORQUE HEAD | 1 | |
| 1J6474 | 39 RING-RETAINING | 2 | |
| 8H9789 | 40 BALL BEARING | 1 | |
| 2H5549 | 41 RING-RETAINING | 2 | |
| 7X5433 | 42 SEAL-LIP TYPE | 1 | |
| 7X5485 | 43 BUSHING | 1 | |
| 1254659 | 44 BOLT | 6 | |
| 1G5974 | 45 PISTON | 7 | |
| 1G5975 | 46 GUIDE | 1 | |
| 7X5477 | 47 GUIDE-RETAINER | 1 | |
| 7X5473 | 48 RETAINER | 1 | |
| 7X5474 | 49 PIN | 3 | |
| 7X5497 | 50 CYLINDER BLOCK | 1 | |
| 7X5472 | 51 WASHER (31.2X40.3X2.7-MM THK) | 1 | |
| 7X5471 | 52 SPRING | 1 | |
| 7X5470 | 53 WASHER-SPECIAL | 1 | |
| 7X5469 | 54 RING-RETAINING | 1 | |
| 0S1594 | 55 BOLT (3/8-16X1-IN) | 3 | |
| 1178295 | 56 PLATE-VALVE | 1 | |
| 7X5489 | 57 PIN | 1 | |
| 7X5468 | 58 BEARING AS-NEEDLE | 1 | |
| 7X5486 | 59 GASKET | 1 | |
| 7X5478 | 60 PIN-SPRING | 1 | |
| 9F2247 | 61 PLUG-PIPE (1/8-27-THD) | 2 | |
| 7X5466 | 62 NUT | 1 | |
| 7X5460 | 63 SLEEVE | 1 | |
| 4D2297 | 64 SEAL-O-RING | 1 | |
| 7X5453 | 65 RING-BACKUP | 1 | |
| 1477286 | 66 GASKET | 1 | |
| 1835429 | 67 PLATE-MOUNTING | 1 | |
| 5S7349 | 68 BOLT (1/4-20X0.5-IN) | 3 | |
| 1835428 | 69 GASKET-COVER | 1 | |
| 1477282 | 70 SPOOL | 1 | |
| 1477284 | 71 CAM-LOCATOR | 1 | |
| 5F9144 | 72 SEAL-O-RING | 1 | |
| 8T4205 | 73 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 0335358 | 74 SCREW-HEAD BOLT | 1 | |
| 0776225 | 75 SWITCH (NEUTRAL START) | 1 | |
| 1835407 | 76 COVER | 1 | |
| 1477291 | 77 SPACER | 1 | |
| 0822753 | 78 BOLT (1/4-20X0.62-IN) | 4 | |
| 5B1866 | 79 PLUG-CUP | 1 | |
| 7X5457 | 80 SPRING | 1 | |
| 7X5459 | 81 BRACKET | 1 | |
| 7X5458 | 82 HANDLE | 1 | |
| 7H3937 | 83 LOCKWASHER | 1 | |
| 2R0504 | 84 NUT (5/16-18-THD) | 1 | |
| 4M6425 | 85 BOLT (5/16-18X1-IN) | 3 | |
| 1G9411 | 86 ADAPTER | 1 | |
| 1G9412 | 87 GASKET | 1 | |
| 1176506 | 88 PLUG-ORIFICE | 1 | |
| 7X5858 | 89 COVER | 1 | |
| 1G5977 | 90 SEAL-O-RING | 1 | |
| 7X5856 | 91 RING | 1 | |
| 1178300 | 92 COVER-PUMP | 1 | |
| 1G5976 | KIT-SEAL | 1 | |
| 7X5431 | KIT-SWASHPLATE | 1 | |
| 9X0803 | KIT-VALVE | 2 | |
| 7X5448 | KIT-PISTON RING | 2 | |
| 7X5866 | KIT-CYLINDER BLOCK (PROPEL MOTOR) | 1 |
