System And Components
145-3623 PUMP GP-PISTONS/N 1FS1-UP; 1XZ1-UP
Group No: 145-3623
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2B0947 | 1 BOLT (1/2-13X2.25-IN) | 2 | |
| 7X9294 | 2 COVER | 1 | |
| 7X9372 | 3 SEAL-O-RING | 1 | |
| 1254659 | 4 BOLT | 12 | |
| 2H5549 | 5 RING-RETAINING | 3 | |
| 8H9789 | 6 BALL BEARING | 2 | |
| 1254660 | 7 BOLT-TORQUE HEAD | 2 | |
| 1J6474 | 8 RING-RETAINING | 3 | |
| 1152160 | 9 FLANGE | 1 | |
| 7X5486 | 10 GASKET | 2 | |
| 1248343 | 11 BEARING-JOURNAL | 4 | |
| 1248349 | 12 PIN | 4 | |
| 7X5485 | 13 BUSHING | 2 | |
| 7X5484 | 14 PIN | 2 | |
| 1389753 | 15 PIN-SLOTTED | 2 | |
| 1G5974 | 17 PISTON | 14 | |
| 1G5975 | 18 GUIDE | 2 | |
| 7X5477 | 19 GUIDE-RETAINER | 2 | |
| 7X5474 | 20 PIN | 6 | |
| 7X5473 | 21 RETAINER | 2 | |
| 7X9373 | 22 SEAL-O-RING | 1 | |
| 7X5497 | 23 CYLINDER BLOCK | 2 | |
| 7X5472 | 24 WASHER (31.2X40.3X2.7-MM THK) | 2 | |
| 7X5471 | 25 SPRING | 2 | |
| 7X5470 | 26 WASHER-SPECIAL | 2 | |
| 7X5469 | 27 RING-RETAINING | 2 | |
| 1092981 | 28 PLATE-VALVE | 1 | |
| 7X5489 | 29 PIN | 2 | |
| 1152159 | 30 SHAFT-PUMP | 1 | |
| 7X5468 | 31 BEARING AS-NEEDLE | 2 | |
| 5B9079 | 32 NUT-JAM (3/8-24-THD) | 2 | |
| 3S2713 | 33 NUT-FULL (3/8-24-THD) | 2 | |
| 7X5446 | 34 RING-RETAINING | 2 | |
| 7X5445 | 35 GUIDE | 2 | |
| 7X5442 | 36 STOP | 2 | |
| 7X5443 | 37 SPRING | 2 | |
| 1805086 | 38 GUIDE-SPRING | 2 | |
| 1805107 | 39 SCREW-SPECIAL | 2 | |
| 4L7711 | 41 SEAL-O-RING | 4 | |
| 1081753 | 42 BEARING | 4 | |
| 7X5450 | 43 PISTON-SERVO | 2 | |
| 7X5439 | 44 COVER | 2 | |
| 9S4191 | 45 PLUG (9/16-18-THD) | 8 | |
| 1G8494 | 46 BOLT (1/4-20X1.125-IN) | 20 | |
| 3D2824 | 48 SEAL-O-RING | 4 | |
| 3J1907 | 49 SEAL-O-RING | 7 | |
| 9S8004 | 50 PLUG (9/16-18-THD) | 3 | |
| 9S4182 | 51 PLUG (7/16-20-THD) | 2 | |
| 3J7354 | 52 SEAL-O-RING | 2 | |
| 5J5793 | 53 BOLT-12 POINT HEAD (1/2-13X2-IN) | 2 | |
| 6V3922 | 54 SEAL-O-RING | 2 | |
| 1H1023 | 55 SEAL-O-RING | 4 | |
| 7X5454 | 56 RING-BACKUP | 4 | |
| 7X9365 | 57 VALVE-BYPASS | 2 | |
| 7X5498 | 58 GASKET | 4 | |
| 7X5466 | 59 NUT | 2 | |
| 1176506 | 60 PLUG-ORIFICE | 2 | |
| 9F2247 | 61 PLUG-PIPE (1/8-27-THD) | 4 | |
| 7X5460 | 62 SLEEVE | 2 | |
| 4D2297 | 63 SEAL-O-RING | 2 | |
| 7X5453 | 64 RING-BACKUP | 2 | |
| 1477286 | 65 GASKET | 1 | |
| 1835429 | 66 PLATE-MOUNTING | 1 | |
| 5S7349 | 67 BOLT (1/4-20X0.5-IN) | 3 | |
| 1835428 | 68 GASKET-COVER | 1 | |
| 1477282 | 69 SPOOL | 1 | |
| 1477284 | 70 CAM-LOCATOR | 1 | |
| 5F9144 | 71 SEAL-O-RING | 1 | |
| 8T4205 | 72 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 8T9003 | 73 BOLT | 1 | |
| 1835407 | 74 COVER | 1 | |
| 0776225 | 75 SWITCH (NEUTRAL START) | 1 | |
| 1477291 | 76 SPACER | 1 | |
| 0822753 | 77 BOLT (1/4-20X0.62-IN) | 4 | |
| 5B1866 | 78 PLUG-CUP | 1 | |
| 7X5457 | 79 SPRING | 2 | |
| 7X5459 | 80 BRACKET | 2 | |
| 1595234 | 81 BRACKET-NEUTRAL | 1 | |
| 7H3937 | 82 LOCKWASHER | 2 | |
| 2R0504 | 83 NUT (5/16-18-THD) | 2 | |
| 1G8639 | 84 SEAL-O-RING | 1 | |
| 1152158 | 85 RING-PILOT | 1 | |
| 7X5490 | 86 COUPLING | 1 | |
| 1152157 | 87 PIN | 1 | |
| 9S8010 | 88 PLUG | 1 | |
| 7X5462 | 89 PLUG | 1 | |
| 2M9780 | 90 SEAL-O-RING | 1 | |
| 0773775 | 91 SHIM | 1 | |
| 1616576 | 92 SPRING | 1 | |
| 1176507 | 93 VALVE-RELIEF | 1 | |
| 1F7958 | 94 NUT-FULL (1/2-13-THD) | 3 | |
| 7X5492 | 95 STUD | 1 | |
| 1152156 | 96 SHAFT-PUMP | 1 | |
| 7X5433 | 97 SEAL-LIP TYPE | 1 | |
| 7X5440 | 98 COVER | 1 | |
| 1178295 | 99 PLATE-VALVE | 1 | |
| 7X5478 | 100 PIN-SPRING | 2 | |
| 1G9412 | 101 GASKET | 1 | |
| 1G9411 | 102 ADAPTER | 1 | |
| 4M6425 | 103 BOLT (5/16-18X1-IN) | 3 | |
| 7B2742 | 104 BOLT (1/4-20X1.25-IN) | 1 | |
| 7X9367 | 105 SPOOL | 1 | |
| 7X5458 | 106 HANDLE | 1 | |
| 1595235 | KIT-SEAL | 1 | |
| 7X5866 | KIT-CYLINDER BLOCK (PROPEL MOTOR) | 2 | |
| 7X5431 | KIT-SWASHPLATE | 2 | |
| 7X5448 | KIT-PISTON RING | 4 | |
| 9X0803 | KIT-VALVE | 4 |
