System And Components
104-7456 LINES GP-CONVEYORS/N ABB430-514; ACM280-281
Group No: 104-7456
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2167961 | 1 VALVE GP-CONTROL (DRAG CONVEYOR, AUGER CONVEYOR) | 2 | |
| 0672551 | 2 CLIP | 2 | |
| 5M3062 | 3 BOLT (3/8-16X0.75-IN) | 5 | |
| 1770264 | 4 FILTER GP-OIL | 1 | |
| 1070099 | 5 MANIFOLD | 1 | |
| 1070002 | 6 MANIFOLD GP-SUCTION | 1 | |
| 1070003 | 7 MANIFOLD | 2 | |
| 1275438 | 8 TUBE AS | 1 | |
| 1285996 | 9 TUBE AS | 1 | |
| 8T9371 | 10 BOLT (3/8-16X0.5-IN) | 1 | |
| 1P4579 | 11 FLANGE-HALF | 12 | |
| 0S1587 | 12 BOLT (1/2-13X1.75-IN) | 32 | |
| 5P8245 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 32 | |
| 1908351 | 14 BRACKET AS | 2 | |
| 1275436 | 15 PLATE | 1 | |
| 5C6565 | 16 BOLT (1/2-13X1.125-IN) | 10 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 26 | |
| 5S7379 | 18 BOLT (3/8-16X0.875-IN) | 16 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 27 | |
| 1546613 | 20 PUMP GP-PISTON (DRAG CONVEYOR, AUGER CONVEYOR) | 1 | |
| 1546612 | 21 PUMP GP-PISTON (DRAG CONVEYOR, AUGER CONVEYOR) | 1 | |
| 8T8917 | 22 BOLT (1/2-13X1.25-IN) | 8 | |
| 8I0843 | 23 MOTOR GP-PISTON | 4 | |
| 6V1320 | 24 SEAL-O-RING | 4 | |
| 5P2566 | 25 BOLT (1/2-13X1.5-IN) | 8 | |
| 1079126 | 26 PLATE | 1 | |
| 7X0294 | 27 BOLT (3/8-16X5-IN) | 2 | |
| 6V8801 | 28 NUT (3/8-16-THD) | 4 | |
| 8I0960 | 29 COUPLING | 1 | |
| 0314847 | 30 SPACER (0.38X0.625X0.25-IN) | 3 | |
| 4L6454 | 31 BOLT (3/8-16X1-IN) | 5 | |
| 1275435 | 32 MANIFOLD GP-COOLING | 1 | |
| 1275437 | 33 PLATE | 1 | |
| 6V8185 | 34 NUT (1/4-20-THD) | 6 | |
| 8T4205 | 35 WASHER-HARD (7.2X14.5X2-MM THK) | 16 | |
| 4S4455 | 36 CLIP | 1 | |
| 8C3793 | 37 BOLT (1/4-20X3.75-IN) | 2 | |
| 8T1682 | 38 ELBOW | 2 | |
| 6K6307 | 39 SEAL-O-RING | 5 | |
| 8T0315 | 40 SEAL-O-RING | 3 | |
| 6V9009 | 41 ELBOW | 3 | |
| 6V8400 | 42 SEAL-O-RING | 6 | |
| 2S4078 | 43 SEAL-O-RING | 7 | |
| 7J6285 | 44 SEAL-O-RING | 1 | |
| 1093657 | 45 CONNECTOR | 3 | |
| 6V9008 | 46 ELBOW | 7 | |
| 6V8625 | 47 ELBOW | 3 | |
| 7M8485 | 48 SEAL-O-RING | 20 | |
| 5K9090 | 49 SEAL-O-RING | 34 | |
| 3K0360 | 50 SEAL-O-RING | 22 | |
| 6V8398 | 51 SEAL-O-RING | 16 | |
| 6V9005 | 52 ELBOW | 5 | |
| 6V9002 | 53 ELBOW | 2 | |
| 6R7111 | 54 HOSE AS | 1 | |
| 9S6130 | 55 PLUG | 2 | |
| 5P3501 | 56 ADAPTER | 1 | |
| 8T8987 | 57 ELBOW | 2 | |
| 6V9854 | 58 ELBOW (SWIVEL) | 2 | |
| 6V8635 | 59 CONNECTOR | 6 | |
| 6V9840 | 60 TEE-SWIVEL | 2 | |
| 6V8627 | 61 ELBOW | 2 | |
| 4J5477 | 62 SEAL-O-RING | 12 | |
| 3J1907 | 63 SEAL-O-RING | 20 | |
| 8C3309 | 64 TEE | 2 | |
| 9S4185 | 65 PLUG (3/4-16-THD) | 3 | |
| 6V8639 | 66 CONNECTOR | 6 | |
| 6V8995 | 67 UNION (STRAIGHT) | 2 | |
| 6V9169 | 68 NUT (13/16-16-THD) | 2 | |
| 6V8633 | 69 CONNECTOR | 1 | |
| 3D2824 | 70 SEAL-O-RING | 2 | |
| 1114171 | 71 HOSE AS | 1 | |
| 1114172 | 72 HOSE AS | 1 | |
| 2D7325 | 73 TEE-PIPE | 1 | |
| 4E9280 | 74 HOSE AS | 1 | |
| 4E3451 | 75 HOSE AS | 1 | |
| 1114175 | 76 HOSE AS | 1 | |
| 1114176 | 77 HOSE AS | 2 | |
| 1114178 | 78 HOSE AS | 1 | |
| 1114179 | 79 HOSE AS | 1 | |
| 1114180 | 80 HOSE AS | 1 | |
| 1006622 | 81 HOSE AS | 1 | |
| 4E5260 | 82 HOSE AS | 1 | |
| 1114181 | 83 HOSE AS | 1 | |
| 1408388 | 84 HOSE AS | 1 | |
| 1114646 | 85 HOSE AS | 1 | |
| 1114647 | 86 HOSE AS | 1 | |
| 1114648 | 87 HOSE AS | 1 | |
| 1095082 | 88 HOSE AS | 1 | |
| 1114454 | 89 HOSE AS | 1 | |
| 5P4115 | 90 WASHER-HARD (7.2X19X2-MM THK) | 4 | |
| 1210379 | 91 HOSE AS | 2 | |
| 1114452 | 92 HOSE AS | 1 | |
| 1114450 | 93 HOSE AS | 1 | |
| 6R2678 | 94 CLAMP | 2 | |
| 7R7952 | 95 COVER | 2 | |
| 7X0265 | 96 BOLT (1/4-20X2.75-IN) | 4 | |
| 5V6152 | 97 CLAMP | 14 | |
| 7R7951 | 98 PLATE | 6 | |
| 7X0264 | 99 BOLT (1/4-20X2.5-IN) | 12 | |
| 8V5718 | 100 CLAMP | 4 | |
| 4V0612 | 101 PLATE | 2 | |
| 8T8911 | 102 BOLT (5/16-18X2-IN) | 2 | |
| 7R7955 | 103 PLATE (SLOTTED) | 1 | |
| 7R7960 | 104 BOLT (1/4-20X2-IN)(1/4-20 THD) | 2 | |
| 1122929 | 105 BRACKET AS | 1 | |
| 7X2552 | 106 BOLT (M16X2X30-MM) | 2 | |
| 8T4122 | 107 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 1129483 | 108 TUBE AS | 1 | |
| 1129484 | 109 TUBE AS | 1 | |
| 8X6790 | 110 HOSE AS | 1 | |
| 6V8724 | 111 ELBOW | 2 | |
| 6V8723 | 112 ELBOW | 4 | |
| 6V8397 | 113 SEAL-O-RING | 20 | |
| 1131547 | 114 HOSE AS | 1 | |
| 1071978 | 115 CLAMP | 2 | |
| 1131548 | 116 PLATE | 2 | |
| 1131549 | 117 BAR | 2 | |
| 6V3966 | 118 FITTING AS | 1 | |
| 7X0268 | 119 BOLT (1/4-20X3.5-IN) | 6 | |
| 1132030 | 120 HOSE AS | 1 | |
| 1132031 | 121 HOSE AS | 1 | |
| 1P4582 | 122 FLANGE-HALF | 4 | |
| 4J0527 | 123 SEAL-O-RING | 2 | |
| 9S8008 | 124 PLUG (1-1/16-12-THD) | 1 | |
| 1114481 | 125 HOSE AS | 1 | |
| 8T9043 | 126 BOLT (5/16-18X0.875-IN) | 3 | |
| 8T4224 | 127 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1126680 | 128 BRACKET AS | 1 | |
| 1285531 | 129 CLAMP-HALF | 2 | |
| 0868656 | 130 NUT | 4 | |
| 1074749 | 131 PLATE | 1 | |
| 4M5282 | 132 BOLT (1/4-20X1.5-IN) | 2 | |
| 8S0948 | 133 CLIP | 3 | |
| 4J0524 | 134 SEAL-O-RING | 6 | |
| 1133353 | 135 ELBOW | 1 | |
| 1133354 | 136 HOSE AS | 1 | |
| 7R7942 | 137 CLAMP | 2 | |
| 1133355 | 138 BRACKET AS | 1 | |
| 1P4577 | 139 FLANGE-HALF | 4 | |
| 3B1915 | 140 BOLT (3/8-16X1.375-IN) | 8 | |
| 5M2894 | 141 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 1207111 | 142 HOSE AS | 1 | |
| 1207112 | 143 HOSE AS | 1 | |
| 1207113 | 144 HOSE AS | 1 | |
| 1207114 | 145 HOSE AS | 1 | |
| 8T2353 | 146 ADAPTER | 4 | |
| 7X8180 | 147 REGULATOR-FLOW | 4 | |
| 8T0788 | 148 ELBOW | 4 | |
| 8C6866 | 149 CONNECTOR | 4 | |
| 1200571 | 150 VALVE GP-CHECK (CONVEYOR) | 2 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 6V8993 | 151 UNION | 1 | |
| 2P1279 | 152 LOCKNUT (9/16-18-THD) | 1 | |
| 6V9876 | 153 ELBOW | 2 | |
| 3J7354 | 154 SEAL-O-RING | 15 | |
| 1207115 | 155 HOSE AS | 1 | |
| 9S4182 | 156 PLUG (7/16-20-THD) | 2 | |
| 9S4181 | 157 PLUG (1-5/16-12-THD) | 2 | |
| 9S8004 | 158 PLUG (9/16-18-THD) | 1 | |
| 4J0520 | 159 SEAL-O-RING | 2 | |
| 8C6427 | 160 ADAPTER | 1 | |
| 8C3446 | 161 VALVE-SAMPLING | 1 | |
| 6V3965 | 162 FITTING (QUICK DISCONNECT) | 8 | |
| 6V0852 | 163 CAP-DUST | 14 | |
| 8C6868 | 164 CONNECTOR | 4 | |
| 0314392 | 165 SEAL-O-RING | 1 | |
| 1322453 | 166 UNION | 4 | |
| 6V9200 | 167 ELBOW | 4 | |
| 1106349 | 168 FITTING AS (QUICK DISCONNECT) | 4 | |
| 0917857 | 169 HOSE AS | 1 | |
| 1374610 | 170 HOSE AS | 1 | |
| 6V8634 | 171 CONNECTOR | 2 | |
| 8T6663 | 172 ADAPTER-PORT | 2 | |
| 5P1075 | 173 WASHER-HARD (10.2X22.5X3-MM THK) | 6 | |
| 8J1256 | 174 CLIP | 1 | |
| 1602251 | 175 SLEEVE-ABRASION (26IN) | ||
| 7K1181 | 176 STRAP-CABLE | 2 | |
| 1783620 | 177 STRAP-DUAL CLAMP | 1 | |
| 5P4116 | 178 WASHER-HARD (8.8X20.5X2-MM THK) | 3 | |
| 7X0293 | 179 BOLT (3/8-16X4.75-IN) | 2 |
