System And Components
241-8637 LINES GP-HEATER & AIR CONDS/N ASW1-156
Group No: 241-8637
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2M1908 | 1 FITTING-BULKHEAD | 2 | |
| 3S2093 | 2 STRAP-CABLE | 1 | |
| 5D1026 | 3 CLAMP-BAND | 8 | |
| 5V6152 | 4 CLAMP | 2 | |
| 5V6439 | 5 PLATE | 3 | |
| 6N8744 | 6 MOUNT | 4 | |
| 7D7026 | 7 CONNECTOR-HOSE | 2 | |
| 9L8781 | 8 WASHER (0.406X1.5X0.188-IN THK) | 8 | |
| 9N3666 | 9 VALVE-MANUAL (COOLANT CONDITIONER) | 8 | |
| 0046810 | 10 ELBOW | 4 | |
| 1106393 | 11 PLATE-INSTRUCTION (AIR CONDITIONER) | 1 | |
| 1145333 | 12 SWITCH AS-PRESSURE (AIR CONDITIONER, HIGH) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9X1386 | SLEEVE | ||
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1180730 | 13 DRYER-REFRIGERANT (RECEIVER) | 1 | |
| 1323968 | 14 CORE AS-CONDENSER | 1 | |
| 1594984 | 15 CLIP | 1 | |
| 1772215 | 16 STRAP-DUAL CLAMP | 2 | |
| 1788510 | 17 PLATE-WELD | 1 | |
| 2066419 | 18 CLAMP-HALF | 4 | |
| 2421511 | 19 BRACKET | 1 | |
| 2421512 | 20 BRACKET | 1 | |
| 2425264 | 21 HOSE AS | 1 | |
| 2435751 | 22 UNION | 1 | |
| 2435753 | 23 UNION | 1 | |
| 2435790 | 24 HOSE AS | 1 | |
| 2435791 | 25 HOSE AS | 1 | |
| 2435792 | 26 HOSE AS | 1 | |
| 2435793 | 27 HOSE AS | 1 | |
| 2435794 | 28 HOSE AS | 1 | |
| 0115224 | 29 BUSHING-REDUCER | 1 | |
| 0950913 | 30 CLIP | 2 | |
| 1189517 | 31 FITTING AS-AIR CONDITIONER | 1 | |
| 3E4052 | CAP-SEAL (HIGH SIDE CHARGE PORT) | 1 | |
| 3E4058 | VALVE AS (REFRIGERANT, HIGH SIDE) | 1 | |
| 1252796 | 32 FITTING AS-AIR CONDITIONER | 1 | |
| 3E4051 | CAP-SEAL (LOW SIDE CHARGE PORT) | 1 | |
| 3E4057 | VALVE AS (REFRIGERANT, LOW SIDE) | 1 | |
| 1285531 | 33 CLAMP-HALF | 2 | |
| 1P6356 | 34 PLATE | 1 | |
| 3E4321 | 35 CLIP (LOOP) | 1 | |
| 4I4655 | 36 CLIP | 1 | |
| 4M0061 | 37 BOLT (5/16-18X0.75-IN) | 1 | |
| 5M3062 | 38 BOLT (3/8-16X0.75-IN) | 2 | |
| 5P4115 | 39 WASHER-HARD (7.2X19X2-MM THK) | 1 | |
| 5P4295 | 40 CLIP | 1 | |
| 6B1628 | 41 BUSHING-REDUCER | 1 | |
| 7K1181 | 42 STRAP-CABLE | 8 | |
| 7S0530 | 43 CLIP | 1 | |
| 7X2533 | 44 BOLT (M6X1X35-MM) | 6 | |
| 7X2535 | 45 BOLT (M6X1X60-MM) | 2 | |
| 8T2561 | 46 WASHER-HARD (10.5X28.5X5-MM THK) | 1 | |
| 8T4121 | 47 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4186 | 48 BOLT (M10X1.5X40-MM) | 4 | |
| 8T4195 | 49 BOLT (M10X1.5X30-MM) | 5 | |
| 8T4224 | 50 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T4896 | 51 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 8T4908 | 52 BOLT (M8X1.25X25-MM) | 2 | |
| 8T6466 | 53 BOLT (M10X1.5X60-MM) | 1 | |
| 9X6165 | 54 WASHER (6.5X22X2.5-MM THK) | 2 | |
| 9X7380 | 55 SEAL-O-RING | 5 | |
| 9X7381 | 56 SEAL-O-RING | 2 | |
| 9X7382 | 57 SEAL-O-RING | 3 | |
| 9X7385 | 58 SEAL-O-RING | 2 | |
| 5P0767 | 59 HOSE (225-CM) | ||
| 9X2390 | 60 HOSE (74-IN) | ||
| 1602245 | 62 SLEEVE-ABRASION | ||
| 1602243 | 63 SLEEVE-ABRASION |
