System And Components
477-1811 VENTILATION GP-PAVERAN ATTACHMENT
Group No: 477-1811
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5084330 | 1 GAUGE-PRESSURE | 1 | |
| 2229208 | 2 TUBE | 1 | |
| 2431147 | 3 HINGE | 1 | |
| 2779952 | 4 PLATE | 1 | |
| 4771821 | 5 PUMP & MTG GP-VENTILATION | 1 | |
| 4771847 | 6 MOTOR & MTG GP-VENTILATION | 1 | |
| 4771848 | 7 LINES GP-HYDRAULIC (FAN, VENTALATION) | 1 | |
| 4771849 | 8 VALVE & MTG GP-FLOW CONTROL | 1 | |
| 4778899 | 9 TUBE | 1 | |
| 4778900 | 10 HOSE | 1 | |
| 4808626 | 11 BLOWER GP-PAVER VENTILATION | 1 | |
| 3B8601 | SETSCREW-SOCKET (3/8-16X0.5-IN) | 2 | |
| 4808628 | 12 CONE | 1 | |
| 4808638 | 13 TUBE AS | 1 | |
| 4808639 | 14 HOSE | 1 | |
| 4816432 | 15 FLANGE AS | 1 | |
| 4816434 | 16 PLATE | 1 | |
| 4816438 | 17 PLATE | 1 | |
| 4816439 | 18 HOUSING AS | 1 | |
| 4816440 | 19 DUCT AS-OUTLET | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 6 | |
| 7T1099 | LINK | 1 | |
| 4845509 | 20 COVER | 1 | |
| 4849608 | 21 DUCT AS | 1 | |
| 4850006 | 22 PLATE | 1 | |
| 4862340 | 23 FILM-IDENTIFICATION (FUMES BLOWER GAUGE) | 1 | |
| 2913957 | 24 CLAMP-HOSE | 3 | |
| 2S3770 | 25 SPACER (11X19X33.5-MM THK) | 2 | |
| 2V3216 | 26 CLIP (LOOP) | 1 | |
| 3445673 | 27 NUT (M6X1-THD) | 4 | |
| 3445674 | 28 NUT (M8X1.25-THD) | 4 | |
| 5C9553 | 29 BOLT (M6X1X16-MM) | 12 | |
| 5P0600 | 30 CLAMP-HOSE | 1 | |
| 5P4116 | 31 WASHER-HARD (8.8X20.5X2-MM THK) | 28 | |
| 6V7743 | 32 LOCKNUT (M6X1-THD) | 1 | |
| 6W9789 | 33 BAR | 1 | |
| 7X2536 | 34 BOLT (M8X1.25X14-MM) | 10 | |
| 8H3127 | 35 BOLT (1/4-20X0.75-IN) | 8 | |
| 8M2771 | 36 CLIP | 1 | |
| 9X2042 | 37 SCREW-TRUSS HEAD (M6X1X12-MM) | 4 | |
| 8T4189 | 38 BOLT (M8X1.25X20-MM) | 6 | |
| 8T4200 | 39 BOLT (M8X1.25X16-MM) | 6 | |
| 8T6869 | 40 BOLT (M8X1.25X60-MM) | 2 | |
| 9X8256 | 41 WASHER (6.6X12X2-MM THK) | 16 | |
| 1440195 | 42 HOSE (41-CM) | ||
| 5P7211 | 43 SEAL (0.16-M EACH) |
