System And Components
7R-4410 ENGINE ARS/N 1JG1-97
Group No: 7R-4410
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0818659 | 1 PUMP GP-PISTON (DRIVE) | 1 | |
| 5P2566 | 2 BOLT (1/2-13X1.5-IN) | 12 | |
| 0314392 | 3 SEAL-O-RING | 1 | |
| 0818660 | 4 PUMP GP-PISTON (DRIVE) | 1 | |
| 5E9057 | 5 MOUNT AS | 1 | |
| 7X0343 | 6 BOLT (5/8-11X1.25-IN) | 8 | |
| 8T4122 | 7 WASHER-HARD (17X32X3.5-MM THK) | 14 | |
| 8T0226 | 8 BOLT (M14X2X45-MM) | 8 | |
| 9R2021 | PLATE | 8 | |
| 7R6305 | 9 MOUNT AS | 2 | |
| 8T7485 | 10 ACTUATOR GP-POWER | 1 | |
| 7R0106 | 11 DRIVE GP-PUMP | 1 | |
| 4L6454 | 12 BOLT (3/8-16X1-IN) | 14 | |
| 5E9056 | 13 MOUNT AS | 1 | |
| 8C7987 | 14 PUMP GP-PISTON (AUXILIARY) | 1 | |
| 2H3934 | 15 SEAL-O-RING | 2 | |
| 5E8701 | 16 PUMP GP-GEAR (VIBRATORY) | 1 | |
| 8C7990 | PUMP | 1 | |
| 8T9979 | 17 SEAL | 1 | |
| 9B7237 | 18 BOLT (3/8-16X1.25-IN) | 4 | |
| 8C7616 | 19 PUMP GP-PISTON (CONVEYOR) | 1 | |
| 6V8981 | 20 ELBOW | 1 | |
| 6V8398 | 21 SEAL-O-RING | 3 | |
| 6V9830 | 22 CAP (ORFS) | 1 | |
| 7R3909 | 23 HOSE AS | 1 | |
| 8C0370 | 24 CLAMP AS | 1 | |
| 6V8625 | 25 ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9W9915 | 26 MOUNT AS | 4 | |
| 9W9952 | 27 WASHER (16.75X86X8-MM THK) | 4 | |
| 7X2475 | 28 BOLT (M16X2X130-MM) | 4 | |
| 8T4132 | NUT (M16X2-THD) | 4 | |
| 9W9953 | 29 SLEEVE | 4 | |
| 8T4896 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 22 | |
| 7R4953 | 31 BRACKET AS | 1 | |
| 7R9623 | 32 SUPPORT AS | 1 | |
| 0818339 | 33 SCREW | 1 | |
| 8C7910 | 34 SWIVEL | 1 | |
| 8T4205 | 35 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 7R8799 | 36 BRACKET | 1 | |
| 7R6261 | 37 FITTING | 1 | |
| 3B6489 | COUPLING-PIPE | 1 | |
| 1T0822 | 38 BOLT-12 POINT HEAD (3/8-16X0.75-IN) | 8 | |
| 8T8919 | 39 BOLT (1/2-13X1.75-IN) | 2 | |
| 6V4429 | 40 BOLT (M16X2X40-MM) | 2 | |
| 8T4223 | 41 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 3B4604 | 42 PIN-COTTER | 1 | |
| 8C5237 | 43 SEAL-O-RING | 1 |
