System And Components
105-4766 ENGINE ARS/N 4XN1-109; 6ZN1-169
Group No: 105-4766
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1054404 | 1 ENGINE AR | 1 | |
| 6V7238 | 2 VALVE-SHUTOFF (ENGINE OIL DRAIN) | 1 | |
| 9W6321 | 3 HOSE AS | 1 | |
| 2P9697 | 4 PLUG | 1 | |
| 9X2488 | 5 CLAMP-HOSE | 1 | |
| 3K0360 | 6 SEAL-O-RING | 2 | |
| 1118206 | 7 BRACKET | 1 | |
| 1089451 | 8 MANIFOLD-ENGINE SENSOR | 1 | |
| 1034977 | 9 SWITCH AS-PRESSURE (ENGINE OIL) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 7N5946 | 10 SWITCH (OIL PRESSURE) | 1 | |
| 1058056 | 11 SENDER AS-PRESSURE (ENGINE OIL) | 1 | |
| 6T2665 | 12 SWITCH AS-TEMPERATURE (COOLANT) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 3E6449 | 13 SWITCH AS-TEMPERATURE (COOLANT) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 7N8532 | 14 SENDER AS-TEMPERATURE (12-VOLT)(COOLANT) | 1 | |
| 8T4136 | 15 BOLT (M10X1.5X25-MM) | 2 | |
| 8T2501 | 16 BOLT (3/8-16X2-IN) | 2 | |
| 6V8801 | 17 NUT (3/8-16-THD) | 2 | |
| 6L9952 | 18 ADAPTER | 2 | |
| 7C4355 | 19 CLIP | 1 | |
| 8C6865 | 20 CONNECTOR | 1 | |
| 4J5477 | 21 SEAL-O-RING | 2 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4896 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 3D2824 | 24 SEAL-O-RING | 2 | |
| 6V8627 | 25 ELBOW | 1 | |
| 3J1907 | 26 SEAL-O-RING | 1 | |
| 6V2455 | 27 SENSOR GP-SPEED (ENGINE SPEED) | 1 | |
| 7T5552 | 28 HOSE AS | 1 | |
| 7E5714 | 29 STRAP-GROUNDING | 1 |
