System And Components
381-0122 LINES GP-AIR COMPRESSORS/N 8RF1-299
Group No: 381-0122
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1623052 | 1 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T0130 | ELBOW | 1 | |
| 3218636 | 2 UNION AS | 1 | |
| 8C8493 | UNION | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 3295528 | 3 ELBOW AS | 1 | |
| 8T8899 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 1488366 | 4 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8987 | ELBOW | 1 | |
| 1488377 | 5 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8980 | ELBOW | 1 | |
| 1488384 | 6 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V8979 | ELBOW | 1 | |
| 1536246 | 7 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 3 | |
| 7X0820 | TEE | 1 | |
| 1645577 | 8 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 6V8984 | ELBOW | 1 | |
| 8X3212 | 9 SPACER (13X19.042X58-MM THK) | 1 | |
| 9X2538 | 10 ELBOW | 1 | |
| 1028705 | 11 PLATE (TOP) | 1 | |
| 1074749 | 12 PLATE (TOP) | 1 | |
| 1620476 | 13 ADAPTER AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1622254 | SEAL | 1 | |
| 3960392 | ADAPTER | 1 | |
| 1772215 | 14 STRAP-DUAL CLAMP | 2 | |
| 2006345 | 15 SADDLE-MOUNTING (DUAL SWIVEL) | 2 | |
| 2042281 | 16 STRAP-CABLE | 4 | |
| 2501448 | 17 CONNECTOR (ORFS) | 1 | |
| 2877279 | 18 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 4J5268 | SEAL-O-RING | 1 | |
| 2815966 | RING-RETAINING | 1 | |
| 4216176 | ADAPTER-ELBOW | 1 | |
| 3510261 | 19 ELBOW AS | 1 | |
| 5P1230 | CONNECTOR | 1 | |
| 6V5063 | SEAL-O-RING | 1 | |
| 3717247 | 20 ADAPTER | 2 | |
| 3779580 | 21 VALVE AS-BALL | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1562525 | VALVE-SHUTOFF | 1 | |
| 3881393 | 22 HOSE AS | 1 | |
| 3881394 | 23 HOSE AS | 1 | |
| 3881395 | 24 HOSE AS | 1 | |
| 3881396 | 25 HOSE AS | 1 | |
| 3900459 | 26 HOSE AS | 1 | |
| 3910259 | 27 HOSE AS | 1 | |
| 3910260 | 28 HOSE AS | 1 | |
| 5248489 | 29 HOSE AS | 1 | |
| 3913919 | 30 HOSE AS | 1 | |
| 3913920 | 31 HOSE AS | 1 | |
| 3934648 | 32 BRACKET AS | 1 | |
| 1028706 | PLATE AS | 1 | |
| 3940291 | 33 GAUGE-PRESSURE (0 TO 12-BAR)(AIR PRESSURE) | 1 | |
| 3940292 | 34 REGULATOR GP-AIR PRESSURE | 1 | |
| 3960407 | 35 COUPLER-QUICK DISCONNECT | 2 | |
| 4198194 | 36 HOSE AS | 1 | |
| 0672551 | 37 CLIP | 8 | |
| 1140489 | 38 BOLT (M5X0.8X75-MM) | 2 | |
| 1488320 | 39 CONNECTOR AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8C6865 | CONNECTOR | 1 | |
| 1488322 | 40 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8640 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488344 | 41 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9162 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1497738 | 42 CLIP (LOOP) | 2 | |
| 1504052 | 43 UNION AS | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V8993 | UNION | 1 | |
| 1V0398 | 44 GROMMET | 1 | |
| 2022762 | 45 CLIP (LOOP) | 4 | |
| 2073643 | 46 CLAMP-HALF | 2 | |
| 2D0388 | 47 GROMMET (25.4-MM ID) | 1 | |
| 2P1279 | 48 LOCKNUT (9/16-18-THD) | 2 | |
| 2P1293 | 49 LOCKNUT (1-3/16-12-THD) | 1 | |
| 3H2900 | 50 GROMMET | 1 | |
| 4L6454 | 51 BOLT (3/8-16X1-IN) | 1 | |
| 4V1939 | 52 CLAMP | 2 | |
| 6V8188 | 53 NUT (1/2-13-THD) | 1 | |
| 6V9168 | 54 NUT (11/16-16-THD) | 4 | |
| 6V9172 | 55 NUT (1-7/16-12-THD) | 1 | |
| 7G3228 | 56 GROMMET | 2 | |
| 8T6912 | 57 BOLT (M8X1.25X50-MM) | 1 | |
| 7X2533 | 58 BOLT (M6X1X35-MM) | 2 | |
| 7X2621 | 59 BOLT (M10X1.5X12-MM) | 1 | |
| 8M2770 | 60 CLIP (LOOP) | 1 | |
| 8T0328 | 61 WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 8T4121 | 62 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4137 | 63 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4172 | 64 BOLT (M10X1.5X80-MM) | 1 | |
| 8T4195 | 65 BOLT (M10X1.5X30-MM) | 6 | |
| 8T4896 | 66 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8T6757 | 67 PLUG-PIPE | 1 | |
| 8T4224 | 68 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 7X0510 | 69 WASHER-HARD (15.5X29X3-MM THK) | 1 |
