System And Components
374-1332 LINES GP-LIFT CYLINDERS/N 8RF1-UP
Group No: 374-1332
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1544890 | 1 BOLT-STACKING (M8X1.25X33-MM) | 9 | |
| 7V5628 | 2 PLATE (TOP) | 2 | |
| 1028703 | 3 PLATE-COVER | 12 | |
| 1028705 | 4 PLATE (TOP) | 1 | |
| 1074749 | 5 PLATE (TOP) | 7 | |
| 1772215 | 6 STRAP-DUAL CLAMP | 2 | |
| 2006345 | 7 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2060452 | 8 PLATE | 9 | |
| 3073529 | 9 HOSE AS | 1 | |
| 3197938 | 10 HOSE AS | 1 | |
| 3393639 | 11 HOSE AS | 1 | |
| 3779052 | 12 HOSE AS | 1 | |
| 3779053 | 13 HOSE AS | 2 | |
| 4154690 | 14 TUBE AS | 1 | |
| 5465996 | 15 TUBE AS | 1 | |
| 5465997 | 22 TUBE AS | 1 | |
| 4171452 | 23 TUBE AS | 1 | |
| 4174992 | 28 HOSE AS | 1 | |
| 4174993 | 29 HOSE AS | 1 | |
| 4174994 | 30 HOSE AS | 1 | |
| 4174995 | 31 HOSE AS | 1 | |
| 4174996 | 32 SEAL | 2 | |
| 4176357 | 33 HOSE AS | 1 | |
| 1488370 | 35 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 1488380 | 36 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8988 | ELBOW | 1 | |
| 1488457 | 37 UNION AS (STRAIGHT) | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8995 | UNION (STRAIGHT) | 1 | |
| 2066410 | 38 CLAMP-HALF | 26 | |
| 1544880 | 39 CLAMP-HALF | 12 | |
| 4V0611 | 40 CLAMP | 2 | |
| 1563617 | 41 CLAMP-HALF | 2 | |
| 1G8781 | 42 CLAMP (HALF) | 14 | |
| 1S0994 | 43 CLIP (LOOP) | 11 | |
| 2042281 | 44 STRAP-CABLE | 6 | |
| 6V3265 | 46 CLIP | 2 | |
| 6V5839 | 47 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V8397 | 48 SEAL-O-RING | 8 | |
| 6V8398 | 49 SEAL-O-RING | 7 | |
| 6V9169 | 50 NUT (13/16-16-THD) | 2 | |
| 7V5626 | 51 CLAMP | 4 | |
| 7X0818 | 52 BOLT (M8X1.25X45-MM) | 1 | |
| 7X2533 | 53 BOLT (M6X1X35-MM) | 10 | |
| 7X2537 | 54 BOLT (M8X1.25X35-MM) | 12 | |
| 8C8451 | 55 BOLT (M6X1X40-MM) | 8 | |
| 8T4137 | 56 BOLT (M10X1.5X20-MM) | 1 | |
| 1563618 | 58 CLAMP-HALF | 2 | |
| 4827185 | 59 TUBE AS | 1 | |
| 4827175 | 60 HOSE AS | 1 | |
| 4827176 | 61 HOSE AS | 1 | |
| 4827177 | 62 HOSE AS | 2 | |
| 4827178 | 63 TUBE AS | 1 | |
| 4827179 | 64 TUBE AS | 1 | |
| 4827180 | 65 TUBE AS | 1 | |
| 4827181 | 66 TUBE AS | 1 | |
| 4827182 | 67 TUBE AS | 1 | |
| 4827183 | 68 TUBE AS | 1 | |
| 4827184 | 69 TUBE AS | 1 |
