System And Components
302-3912 WIRING GP-POWER RECEPTACLES/N TFZ1-UP
Group No: 302-3912
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6Y6815 | 1 GASKET AS (CONNECTOR) | 1 | |
| 1971381 | 2 CIRCUIT BREAKER AS (35-AMPERE) | 1 | |
| 2417709 | 3 PLATE | 1 | |
| 2468370 | 4 GROMMET | 1 | |
| 3067615 | 5 CABLE AS | 1 | |
| 2867243 | 6 FILM-INSTRUCTION (HOLD FREQUENCY, READ OMM) | 1 | |
| 3023911 | 7 HARNESS AS-SWITCH | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 5P2321 | TERMINAL-FORK (14-GA TO 16-GA, NO. 6 SCREW) | 2 | |
| 1809339 | PIN-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 3067612 | 8 PANEL GP-POWER | 1 | |
| 4D1836 | 9 SWITCH-TOGGLE (HOLD FREQUENCY) | 1 | |
| 5C2890 | 10 NUT (M6X1-THD) | 4 | |
| 5P8440 | 11 GROMMET | 1 | |
| 7K1181 | 12 STRAP-CABLE | 4 | |
| 7X7729 | 13 WASHER (11X25X3-MM THK) | 4 | |
| 8T4136 | 14 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4138 | 15 BOLT (M6X1X20-MM) | 4 | |
| 9G4191 | 16 GROMMET | 1 | |
| 9X8256 | 17 WASHER (6.6X12X2-MM THK) | 8 | |
| 2462641 | 18 PADLOCK GP | 1 | |
| 5P8500 | KEY | 1 |
