System And Components
239-3056 ENGINE ARS/N B4G1-UP; A5P1-UP
Group No: 239-3056
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4278 | 1 CLAMP-HOSE | 1 | |
| 5P3741 | 2 TEE-PIPE | 1 | |
| 7N8532 | 3 SENDER AS-TEMPERATURE (12-VOLT)(COOLANT) | 1 | |
| 6V8378 | NUT (10-32-THD) | 1 | |
| 8F1434 | LOCKWASHER | 1 | |
| 8T0328 | WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 8C3445 | 4 CAP-DUST | 1 | |
| 8T7859 | 5 CONNECTOR | 1 | |
| 9X2488 | 6 CLAMP-HOSE | 1 | |
| 2953145 | 7 SENDER AS-PRESSURE (ENGINE OIL) | 1 | |
| 4B2049 | NUT (10-32-THD) | 1 | |
| 8F1434 | LOCKWASHER | 1 | |
| 1166680 | 8 SENSOR AS-SPEED (ENGINE) | 1 | |
| 1715349 | STRAP-MARKER | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 9X1386 | SLEEVE (14-CM) | ||
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1423388 | 9 SPACER-FAN | 1 | |
| 1570670 | 10 CAP-DUST | 1 | |
| 1620782 | 11 SWITCH AS-PRESSURE (ENGINE OIL) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1652273 | 12 VALVE AS-SHUTOFF (ENGINE OIL DRAIN) | 1 | |
| 6V7238 | VALVE-SHUTOFF | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1779752 | 13 ENGINE AR-PRIMARY | 1 | |
| 1833633 | 14 HOSE AS | 1 | |
| 2033219 | 15 SWITCH AS-TEMPERATURE (COOLANT) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 2292884 | 16 GUARD AS-ALTERNATOR | 1 | |
| 2308258 | 17 TUBE AS | 1 | |
| 2632161 | 18 GAUGE AS-OIL LEVEL (DIPSTICK)(ENGINE) | 1 | |
| 2388289 | 19 PIPE AS | 1 | |
| 2425938 | 20 BRACKET AS | 1 | |
| 2509247 | 21 SPIDER AS-FAN (9-BLADE) | 1 | |
| 1533061 | 22 BOLT (M8X1.25X130-MM) | 4 | |
| 1549025 | 23 VALVE-SAMPLING (COOLANT) | 1 | |
| 1595255 | 24 ADAPTER | 1 | |
| 1645590 | 25 VALVE AS-FLUID SAMPLING (ENGINE OIL) | 1 | |
| 8C3446 | VALVE-SAMPLING | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1654935 | 26 PLUG AS | 1 | |
| 6V9510 | PLUG | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 5C9553 | 27 BOLT (M6X1X16-MM) | 1 | |
| 5J4715 | 28 WASHER (10.3X20.6X4.2-MM THK) | 1 | |
| 5K5068 | 29 FITTING-PIPE (1/8-27 PTF) | 1 | |
| 5P2369 | 30 CLIP (LOOP) | 1 | |
| 5P9186 | 31 SEAL-O-RING | 1 | |
| 6B5072 | 32 ADAPTER | 1 | |
| 7K1181 | 33 STRAP-CABLE | 1 | |
| 8L5008 | 34 ELBOW-PIPE | 1 | |
| 8T4189 | 35 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4200 | 36 BOLT (M8X1.25X16-MM) | 4 | |
| 8T4205 | 37 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 8T4224 | 38 WASHER-HARD (8.8X16X2-MM THK) | 12 | |
| 8T7876 | 39 SEAL-O-RING | 1 | |
| 8C3681 | 40 HOSE (140-CM) | ||
| 1303880 | 41 PULLEY-FAN DRIVE | 1 | |
| 3N1491 | 42 V-BELT SET (INCLUDES 2-BELTS)(FAN DRIVE) | 1 | |
| 4V0612 | 43 PLATE | 1 | |
| 7V6659 | 44 CLAMP-DOUBLE | 2 | |
| 7X0440 | 45 BOLT (5/16-18X1.75-IN) | 1 |
