System And Components
469-0005 CONTROL GP-ELECTRONIC -GROUND LEVEL SHUTDOWNS/N TRG1-UP
Group No: 469-0005
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1342252 | 1 SENSOR GP-TEMPERATURE (8-VOLT)(AMBIENT AIR) | 1 | |
| 4193911 | 2 LAMP GP-INDICATOR (12/24-VOLT, AMBER)(TRANSMISSION) | 2 | |
| 4193912 | 3 LAMP GP-INDICATOR (BLUE)(VIMS SERVICE) | 1 | |
| 4432975 | 4 LAMP GP-INDICATOR (12/24-VOLT, GREEN)(GREEN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3E5169 | 5 GUARD-SWITCH | 1 | |
| 3V4694 | 6 PLUG-BUTTON | 1 | |
| 7K1181 | 7 STRAP-CABLE | 16 | |
| 7P3895 | 8 BUTTON-PLUG | 1 | |
| 2702679 | 9 LOCKWASHER | 1 | |
| 3100674 | 10 LOCKWASHER | 1 | |
| 3311066 | 11 BLOCK AS-TERMINAL | 3 | |
| 3525703 | 12 PLATE | 1 | |
| 3534515 | 13 SWITCH GP-TOGGLE (STAIRWAY LIGHTS) | 1 | |
| 3534515 | 13A SWITCH GP-TOGGLE (GROUND LEVEL SHUTDOWN) | 1 | |
| 3534515 | 13B SWITCH GP-TOGGLE (ENGINE FLOODLIGHTS) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 3E3390 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 2712178 | SWITCH AS-TOGGLE | 1 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 3824475 | 14 SWITCH GP-ROTARY (2-POSITION)(TRANSMISSION LOCKOUT) | 1 | |
| 3824475 | 14A SWITCH GP-ROTARY (2-POSITION)(STARTER LOCKOUT) | 1 | |
| 4195974 | 16 ADAPTER AS (AT04-6P TO RJ45) | 1 | |
| 4322668 | NUT (13/16-28-THD) | 1 | |
| 4305165 | 18 SWITCH AS-DISCONNECT (MASTER) | 1 | |
| 6V8149 | NUT (M12X1.75-THD) | 4 | |
| 8J8659 | WASHER (0.75X1.19X0.125-MM THK) | 4 | |
| 4400535 | 19 CAP AS | 1 | |
| 4630212 | 20 SPACER (8.8X16X4-MM THK) | 2 | |
| 4684381 | 21 PLATE | 1 | |
| 4883971 | 22 BOLT AS | 2 | |
| 4883974 | 23 BOLT AS | 2 | |
| 4911884 | 24 BRACKET | 4 | |
| 4916360 | 25 PLATE AS | 1 | |
| 7T1099 | LINK | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 15 | |
| 4916362 | 26 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 12 | |
| 5197470 | 27 COVER AS | 1 | |
| 8T2659 | LOCKNUT (M4X0.7-THD) | 12 | |
| 8T4171 | BOLT (M6X1X12-MM) | 2 | |
| 9X2038 | WASHER (7X19X2-MM THK) | 2 | |
| 0966166 | WASHER-HARD (4.5X9X1-MM THK) | 24 | |
| 1622165 | BOLT-SOCKET HEAD (M4X0.7X16-MM) | 12 | |
| 3908559 | MAGNET | 2 | |
| 4151789 | SPACER (6.6X11X6-MM THK) | 2 | |
| 4916368 | 28 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 5001850 | 29 FILM-IDENTIFICATION (PANEL) | 1 | |
| 5025089 | 30 PLATE | 1 | |
| 5089000 | 31 HARNESS AS-PANEL | 1 | |
| 2039007 | 32 NUT (1-1/2-18-THD) | 1 | |
| 2110052 | 33 NUT (1-11/16-18-THD) | 1 | |
| 2253109 | 34 SCREW-TRUSS HEAD (M4X0.7X14-MM) | 12 | |
| 2P1279 | 35 LOCKNUT (9/16-18-THD) | 1 | |
| 3445674 | 36 NUT (M8X1.25-THD) | 2 | |
| 5P4116 | 37 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 8T4179 | 38 BOLT (M12X1.75X20-MM) | 6 | |
| 8T4189 | 39 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4223 | 40 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T4224 | 41 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T7547 | 42 BOLT (M8X1.25X30-MM) | 2 | |
| 9J5709 | 43 PLUG-BUTTON | 2 | |
| 9X2041 | 44 SCREW-TRUSS HEAD (M10X1.5X20-MM) | 9 | |
| 7X7729 | 45 WASHER (11X25X3-MM THK) | 8 | |
| 8T4137 | 46 BOLT (M10X1.5X20-MM) | 8 |
