System And Components
206-6693 BURNER GP -DIESEL HEATPART OF 241-6807 INSTALLATION AR-SCREED
Group No: 206-6693
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8I0997 | 1 CONNECTOR AS | 4 | |
| 8I0998 | 2 BRACKET-MOUNTING | 3 | |
| 1022698 | 3 HOUSING-BLOWER | 4 | |
| 1022725 | 4 ADAPTER | 4 | |
| 1118140 | 5 VALVE-CHECK (FUEL FLOW) | 4 | |
| 1419272 | 6 PLATE-COVER | 4 | |
| 1458985 | 7 CHAMBER AS | 4 | |
| 1879608 | 8 NOZZLE | 4 | |
| 1879760 | 9 PLATE | 4 | |
| 1911036 | 10 PLUG | 4 | |
| 1915983 | 11 CONE AS | 4 | |
| 9X6259 | SCREW-MACHINE (6-32X0.375-IN) | 1 | |
| 2159198 | LOCKNUT | 1 | |
| 2066728 | 12 WHEEL-BLOWER | 4 | |
| 2066742 | 13 CHAMBER AS | 2 | |
| 8T5911 | NUT-WELD (1/2-13-THD) | 4 | |
| 2066744 | 14 PLATE-MOUNTING | 1 | |
| 2066748 | 15 INSULATION | 2 | |
| 2066749 | 16 MOTOR GP-ELECTRIC (24-VOLT)(BLOWER) | 4 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 2163459 | 17 CHAMBER AS | 2 | |
| 8T5911 | NUT-WELD (1/2-13-THD) | 6 | |
| 2163460 | 18 INSULATION | 2 | |
| 0309612 | 19 SCREW-FORMING (10-24X0.5-IN) | 16 | |
| 4B4274 | 20 WASHER (5.5X13X1.2-MM THK) | 8 | |
| 5P1076 | 21 WASHER-HARD (13.5X30X4-MM THK) | 16 | |
| 5P2566 | 22 BOLT (1/2-13X1.5-IN) | 6 | |
| 6V5764 | 23 SCREW-MACHINE (10-32X0.625-IN) | 16 | |
| 6V8185 | 24 NUT (1/4-20-THD) | 16 | |
| 6V8188 | 25 NUT (1/2-13-THD) | 8 | |
| 8M6802 | 26 SCREW-HEX SOCKET (1/4-20X1-IN) | 16 | |
| 8T4205 | 27 WASHER-HARD (7.2X14.5X2-MM THK) | 16 | |
| 8T4223 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 36 | |
| 8T4835 | 29 BOLT (1/2-13X2-IN) | 20 | |
| 8T8917 | 30 BOLT (1/2-13X1.25-IN) | 16 | |
| 8T8919 | 31 BOLT (1/2-13X1.75-IN) | 2 | |
| 9F8125 | 32 LOCKWASHER | 24 |
