System And Components
253-4752 ADJUSTER GP-HEIGHTPART OF 294-0947 SCREED AR
Group No: 253-4752
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1A4168 | 1 NUT (1-1/4-12-THD) | 8 | |
| 3B8488 | 2 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 3B8489 | 3 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 8I0256 | 4 BUSHING | 8 | |
| 8I0267 | 5 CAP | 4 | |
| 8I0740 | 6 COUPLING GP | 2 | |
| 4B9806 | SETSCREW-SOCKET (1/4-20X0.25-IN) | 1 | |
| 8I0901 | 7 TRUNNION | 2 | |
| 8I0902 | 8 SPACER (0.75X1.50X1-IN THK) | 4 | |
| 3546744 | 9 TUBE AS | 4 | |
| 1022739 | 10 KEY-SQUARE | 2 | |
| 1066340 | 11 SPACER (10.74X17.14X7-MM THK) | 2 | |
| 1134339 | 12 SPACER (10.5X18X21-MM THK) | 8 | |
| 1654655 | 13 BLOCK AS (PIVOT) | 2 | |
| 1654731 | 14 PIN AS | 2 | |
| 1855431 | 15 BOLT-SPECIAL | 8 | |
| 1855432 | 16 LOCK | 8 | |
| 1962503 | 17 JACK GP-HEIGHT ADJUSTER | 2 | |
| 1962564 | 18 BRACKET AS | 1 | |
| 1962566 | 19 POINTER | 4 | |
| 1982819 | 20 RING-RETAINING | 8 | |
| 2066621 | 21 PLATE AS | 2 | |
| 2066622 | 22 FRAME AS (LH) | 1 | |
| 2066630 | 23 BRACKET AS | 1 | |
| 2539037 | 24 BOLT (3/4-16X1.75-IN) | 4 | |
| 2772006 | 25 MOTOR GP-POWER ADJUSTER | 2 | |
| 2773180 | 26 FILM-IDENTIFICATION (HEIGHT ADJUST) | 2 | |
| 2773181 | 27 FILM-IDENTIFICATION (SLOPE) | 2 | |
| 2947761 | 28 FRAME AS (RH) | 1 | |
| 1744883 | 29 STUD (3/8-16X2-IN)(BOLT) | 2 | |
| 4L6454 | 30 BOLT (3/8-16X1-IN) | 12 | |
| 5P1075 | 31 WASHER-HARD (10.2X22.5X3-MM THK) | 22 | |
| 5P2566 | 32 BOLT (1/2-13X1.5-IN) | 8 | |
| 5P8167 | 33 BOLT (3/8-16X0.625-IN) | 4 | |
| 6V8182 | 34 NUT (3/4-10-THD) | 6 | |
| 6V8801 | 35 NUT (3/8-16-THD) | 2 | |
| 7X0372 | 36 BOLT (3/4-10X4.25-IN) | 2 | |
| 8T4223 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4896 | 38 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 8T4994 | 39 WASHER-HARD (20X36.5X3.5-MM THK) | 8 | |
| 8T9377 | 40 BOLT (3/8-16X2.25-IN) | 8 |
