System And Components
328-3509 ADJUSTER GP-HEIGHTPART OF 328-3497 SCREED AR
Group No: 328-3509
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1A4168 | 1 NUT (1-1/4-12-THD) | 8 | |
| 3B8488 | 2 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 3B8489 | 3 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 8I0256 | 4 BUSHING | 8 | |
| 8I0267 | 5 CAP | 4 | |
| 8I0740 | 6 COUPLING GP | 2 | |
| 4B9806 | SETSCREW-SOCKET (1/4-20X0.25-IN) | 1 | |
| 1022739 | 7 KEY-SQUARE | 2 | |
| 1066340 | 8 SPACER (10.74X17.14X7-MM THK) | 2 | |
| 1134339 | 9 SPACER (10.5X18X21-MM THK) | 4 | |
| 1654655 | 10 BLOCK AS | 2 | |
| 1654731 | 11 PIN AS | 2 | |
| 1855431 | 12 BOLT-SPECIAL | 8 | |
| 1962503 | 13 JACK GP-HEIGHT ADJUSTER | 2 | |
| 1962564 | 14 BRACKET AS | 1 | |
| 1962566 | 15 POINTER | 4 | |
| 1982819 | 16 RING-RETAINING | 8 | |
| 2066630 | 17 BRACKET AS | 1 | |
| 2772006 | 18 MOTOR GP-POWER ADJUSTER | 2 | |
| 2773180 | 19 FILM-IDENTIFICATION (HEIGHT ADJUST) | 2 | |
| 2773181 | 20 FILM-IDENTIFICATION (SLOPE) | 2 | |
| 2796482 | 21 SPACER (38X21X20-MM THK) | 4 | |
| 3343363 | 23 FRAME AS (LH) | 1 | |
| 3343365 | 24 FRAME AS (RH) | 1 | |
| 3343367 | 25 PLATE AS | 2 | |
| 3418407 | 26 LOCK | 8 | |
| 3546744 | 27 TUBE AS | 4 | |
| 1744883 | 28 STUD (3/8-16X2-IN) | 2 | |
| 4L6454 | 29 BOLT (3/8-16X1-IN) | 2 | |
| 6V8801 | 30 NUT (3/8-16-THD) | 2 | |
| 7X2566 | 31 BOLT (M20X2.5X110-MM) | 2 | |
| 7X7729 | 32 WASHER (11X25X3-MM THK) | 22 | |
| 8T4123 | 33 WASHER (3.62X5.75X0.375-MM THK) | 6 | |
| 8T4131 | 34 NUT (M20X2.5-THD) | 6 | |
| 8T4136 | 35 BOLT (M10X1.5X25-MM) | 10 | |
| 8T4183 | 36 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4191 | 37 BOLT (M10X1.5X16-MM) | 4 | |
| 8T4196 | 38 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4223 | 39 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4896 | 40 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 8T5005 | 41 BOLT (M10X1.5X70-MM) | 4 | |
| 8T5460 | 42 BOLT (M20X2.5X40-MM) | 4 | |
| 8T5439 | 43 WASHER-HARD (21.5X45X6-MM THK) | 2 |
