Assembly
100%

479-6017 MOUNTING GP-ALTERNATOR & COMPRS/N T4F1-UP; TXX1-UP

Group No: 479-6017
Part NumberPart NameQty
24323101 COVER2
33649532 TENSIONER-BELT1
27925893 PULLEY AS-IDLER (8-GROOVE)1
39101514 BRACKET-SUPPORT1
39101525 BRACKET-SUPPORT1
5P82456 WASHER-HARD (13.5X25.5X3-MM THK)4
6V38227 BOLT (M10X1.5X35-MM)2
28730498 STUD (M10X1.5X50-MM)2
6V58399 WASHER (11X21X2.5-MM THK)5
6V798110 BOLT (M10X1.5X70-MM)1
6V814911 NUT (M12X1.75-THD)2
7X090912 BOLT (M12X1.75X140-MM)2
