System And Components
566-9180 KIT-AIR CLEANERS/N DN71-UP
Group No: 566-9180
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5669184 | 1 BRACKET | 1 | |
| 8T4189 | 2 BOLT (M8X1.25X20-MM) | 4 | |
| 5P4116 | 3 WASHER-HARD (8.8X20.5X2-MM THK) | 8 | |
| 7X7729 | 4 WASHER (11X25X3-MM THK) | 2 | |
| 8T4136 | 5 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4223 | 6 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4956 | 7 BOLT (M12X1.75X35-MM) | 4 | |
| 1495628 | 8 WASHER (8.3X38.1X1.2-MM THK) | 1 | |
| 1510802 | 9 KNOB | 1 | |
| 1055211 | 10 PLUG AS | 4 | |
| 6V9028 | SEAL-O-RING | 1 | |
| 2416157 | PLUG | 1 | |
| 4969840 | 11 AIR CLEANER GP (INTAKE) | 1 | |
| 5516681 | 12 AIR CLEANER GP (LEFT MOUNT) | 1 | |
| 5669185 | 13 TUBE AS | 1 | |
| 5669186 | 14 TUBE | 1 | |
| 5701470 | 15 COVER AS-ACCESS | 1 | |
| 5701481 | 16 BRACKET | 1 | |
| 5701482 | 17 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 5701488 | 18 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T4908 | 19 BOLT (M8X1.25X25-MM) | 4 |
