532-8707 MODULE GP-COOLINGS/N DN71-UP

Group No: 532-8707
Part NumberPart NameQty
45587091 TUBE2
11829902 MOUNT AS8
56527023 HOSE4
18861854 GROMMET1
20874485 CLAMP8
21770886 HOSE4
53287087 FRAME GP-COOLING1
53287208 COOLING GP1
53287219 FAN GP-SUCTION1
532873410 TUBE4
198476711 WASHER-HARD (13.5X30X12-MM THK)2
208613512 CLIP (SLOT)4
208613613 CLIP (TAB)4
329335614 NUT (M12X1.75-THD)4
344567415 NUT (M8X1.25-THD)2
344567516 NUT (M10X1.5-THD)14
5V050017 WASHER (16.5X75X6-MM THK)28
8T412118 WASHER-HARD (11X21X2.5-MM THK)91
8T413219 NUT (M16X2-THD)4
8T417321 BOLT (M16X2X110-MM)16
8T418322 BOLT (M12X1.75X40-MM)56
8T418623 BOLT (M10X1.5X40-MM)5
8T419324 BOLT (M16X2X50-MM)12
8T419525 BOLT (M10X1.5X30-MM)65
8T422326 WASHER-HARD (13.5X25.5X3-MM THK)60
7X057927 WASHER-HARD (8.8X25.5X2-MM THK)6
8T754728 BOLT (M8X1.25X30-MM)4
9M795929 CLAMP-HOSE4
9X825730 WASHER (17.5X30X3.5-MM THK)12
482178631 MOUNT AS8
308913132 SEAL (1521-MM EACH)
8T498433 CLAMP-HOSE4
8T419634 BOLT (M10X1.5X35-MM)7
364979435 BOLT (M10X1.5X55-MM)8
7X772936 WASHER (11X25X3-MM THK)8
3B461837 PIN-COTTER8
