System And Components
532-8722 MODULE GP-COOLINGS/N DN71-UP
Group No: 532-8722
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1182990 | 1 MOUNT AS | 16 | |
| 5328721 | 2 FAN GP-SUCTION | 1 | |
| 5328723 | 3 FRAME GP-COOLING | 1 | |
| 5328732 | 4 COOLING GP | 1 | |
| 5334380 | 5 LINES GP-OIL COOLER | 1 | |
| 3293356 | 6 NUT (M12X1.75-THD) | 4 | |
| 3445675 | 7 NUT (M10X1.5-THD) | 14 | |
| 5V0500 | 8 WASHER (16.5X75X6-MM THK) | 28 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 83 | |
| 8T4132 | 10 NUT (M16X2-THD) | 4 | |
| 8T4173 | 11 BOLT (M16X2X110-MM) | 16 | |
| 8T4183 | 12 BOLT (M12X1.75X40-MM) | 56 | |
| 8T4193 | 13 BOLT (M16X2X50-MM) | 12 | |
| 8T4195 | 14 BOLT (M10X1.5X30-MM) | 62 | |
| 8T4223 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 60 | |
| 9X8257 | 16 WASHER (17.5X30X3.5-MM THK) | 12 | |
| 8T3425 | 17 CHANNEL-TRIM (0.4-M) | ||
| 8T3425 | 17A CHANNEL-TRIM (0.3-M EACH) | ||
| 3089131 | 18 SEAL (1525-MM EACH) | ||
| 8T4196 | 19 BOLT (M10X1.5X35-MM) | 7 | |
| 7X7729 | 20 WASHER (11X25X3-MM THK) | 8 | |
| 3649794 | 21 BOLT (M10X1.5X55-MM) | 8 |
