System And Components
355-1132 LINES GP-AIRS/N MJ91-UP
Group No: 355-1132
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9N5085 | 1 CLAMP | 4 | |
| 3458988 | 2 BRACKET AS | 1 | |
| 4K9097 | NUT-WELD (5/16-18-THD) | 6 | |
| 8K7186 | NUT-WELD (7/16-14-THD) | 2 | |
| 4598403 | 3 MANIFOLD | 1 | |
| 3560366 | 4 TUBE-AIR | 1 | |
| 3560367 | 5 TUBE AS | 1 | |
| 3560368 | 6 TUBE-AIR | 1 | |
| 3560369 | 7 TUBE AS | 1 | |
| 3560371 | 8 BRACKET | 1 | |
| 3560372 | 9 BRACKET | 1 | |
| 3560374 | 10 SUPPORT | 4 | |
| 3576735 | 11 HOSE AS | 2 | |
| 3646368 | 12 TUBE-VENTURI | 1 | |
| 3655486 | 13 CLAMP | 4 | |
| 3718028 | 14 BRACKET | 1 | |
| 3740645 | 15 BRACKET | 1 | |
| 0L2070 | 16 BOLT (3/8-16X2.25-IN) | 4 | |
| 0S1594 | 17 BOLT (3/8-16X1-IN) | 4 | |
| 4B3388 | 18 BOLT (5/16-18X1.125-IN) | 2 | |
| 1092332 | 19 SEAL-O-RING | 2 | |
| 2735039 | 20 SEAL-O-RING | 1 | |
| 7X0319 | 21 BOLT (7/16-14X4.25-IN) | 2 | |
| 2M2488 | 22 STUD-TAPERLOCK (3/8-16X3.59-IN) | 8 | |
| 3147599 | 23 CLAMP-BAND | 4 | |
| 3B1915 | 24 BOLT (3/8-16X1.375-IN) | 4 | |
| 5M2894 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P8244 | 26 WASHER-HARD (12X22.5X2.5-MM THK) | 2 | |
| 9M1974 | 27 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9S8752 | 28 NUT-FULL (3/8-16-THD) | 8 | |
| 9X6458 | 29 WASHER-HARD (10.2X22.5X3-MM THK) | 16 |
