System And Components
504-4513 LINES GP-AIRS/N DN81-UP
Group No: 504-4513
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3678480 | 1 GROMMET | 3 | |
| 5131820 | 2 HOSE AS | 1 | |
| 5656119 | 3 HOSE AS | 1 | |
| 5363781 | 4 TUBE AS | 1 | |
| 1065125 | 5 CLIP (SLOT) | 6 | |
| 1065126 | 6 CLIP (TAB) | 6 | |
| 1187313 | 7 BOLT (M16X2X70-MM) | 8 | |
| 1P4584 | 8 FLANGE-HALF | 8 | |
| 1P4585 | 9 FLANGE-HALF | 4 | |
| 2P3538 | 10 SEAL-O-RING | 2 | |
| 6J2680 | 11 SEAL-O-RING | 3 | |
| 7X7729 | 12 WASHER (11X25X3-MM THK) | 2 | |
| 7X7906 | 13 CLIP (TAB) | 3 | |
| 7X7907 | 14 CLIP (SLOT) | 3 | |
| 8T4183 | 15 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4194 | 16 BOLT (M12X1.75X50-MM) | 3 | |
| 8T4196 | 17 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 14 | |
| 8T4648 | 19 BOLT (M12X1.75X70-MM) | 2 | |
| 8T4910 | 20 BOLT (M12X1.75X60-MM) | 4 | |
| 9X7456 | 21 GROMMET | 6 | |
| 9X8257 | 22 WASHER (17.5X30X3.5-MM THK) | 8 | |
| 8T0568 | 23 SEAL-O-RING | 1 | |
| 8T6466 | 24 BOLT (M10X1.5X60-MM) | 1 | |
| 1984778 | 25 WASHER-HARD (13.5X30X12-MM THK) | 1 | |
| 5P1076 | 26 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 4489445 | 27 STUD (M12X1.75X115-MM) | 3 | |
| 3293356 | 28 NUT (M12X1.75-THD) | 4 | |
| 5535827 | 29 PLATE | 1 | |
| 5656120 | 30 HOSE AS | 1 |
