System And Components
571-0551 MOUNTING GP-AIR CLEANERS/N DN8106-UP
Group No: 571-0551
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4189 | 1 BOLT (M8X1.25X20-MM) | 8 | |
| 5P4116 | 2 WASHER-HARD (8.8X20.5X2-MM THK) | 8 | |
| 8T4121 | 3 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4136 | 4 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4223 | 5 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4956 | 6 BOLT (M12X1.75X35-MM) | 8 | |
| 8U6668 | 7 VALVE | 2 | |
| 1055211 | 8 PLUG AS | 4 | |
| 6V9028 | SEAL-O-RING | 1 | |
| 2416157 | PLUG | 1 | |
| 1495628 | 9 WASHER (8.3X38.1X1.2-MM THK) | 4 | |
| 1510802 | 10 KNOB | 4 | |
| 4969840 | 11 AIR CLEANER GP | 1 | |
| 5516681 | 12 AIR CLEANER GP | 1 | |
| 5710547 | 13 COVER AS | 1 | |
| 5881791 | 14 COVER AS | 1 | |
| 5792932 | 15 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 10 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 5792933 | 16 BRACKET AS | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 5898852 | 17 PLATE | 1 | |
| 8T4195 | 18 BOLT (M10X1.5X30-MM) | 2 |
